LL-W-V
Internal wall mounted photo-diode type light level sensor. Accuracy 5% across range, field of view 90 Degrees with 21m coverage. Range 10-2000 Lux with a 0-10V output. Housing: Material flame retardant ABS, polypropylene, IP30. Ambient range: Temp. -10 to +40°C, 90% RH non-condensing. Power supply 24vDC...
LPMS-CURS3-RS232
LPMS-CURS3 RS232 OEM: 9-Axis IMU/AHRS/Motion Sensor. Accelerometer: 3 axes, ±2/±4/±8/±16 g (16 bits); Gyroscope: 3 axes, ±125/±245/±500/±1000/±2000°/s (16 bits); Magnetometer: 3 axes, ±4/±8/±12/±16 gauss (16 bits); Barometric Pressure: 300 to 1100hPa. Data output format: Raw Data; Euler Angle; Quaternion @ up to 400Hz. Power supply 5 to 15vDC (RS232 Port),..
LPMS-IG1 9-Axis High Precision IMU
The LPMS-IG1 Motion Sensor is a high precision, miniature, inertial measurement unit (IMU). The LPMS-IG1 features a 3-axis accelerometer, Dual gyroscopes and magnetometer sensors and can provide raw data, euler angle or quaternion data output formats via USB, RS232, RS485 or CANBus protocols. The sensors are housed in an IP67..
LPMS-IG1-RS232
A 9-Axis IMU with High Precision Orientation and Linear Acceleration Measurements. The LPMS-IG1-RS232 is supplied in an IP67 Rated Enclosure with RS232 and USB connectivity. Accelerometer: 3 axes, ±2/±4/±8/±16g (16 bits). Dual Gyroscopes: #1: 3 axes, ±400°/s (24 bits); #2: ±1000/±2000dps, (16 bits). Static Orientation Stability: #1: 4°/hour, #2: 6°/hour...
LPMS-INC1 High Precision MEMS Inclinometer
The LPMS-INC1 is a high-precision, high-stability dual-axis inclinometer sensor based on MEMS technology. Utilising an integrated processing algorithm to filter and calibrate built-in accelerometer data to deliver real-time raw acceleration, calibrated acceleration, inclination, and temperature measurements. Designed for versatility across applications, it supports RS232 and CANBus communication options...
LPMS-INC1-CAN
LPMS-INC1-CAN: High Precision MEMS Dual Axis Inclinometer with CANOpen connectivity. Inclinometers Measurement Range X: ±90°; Y: ±90°. Resolution: <0.001° (32-Bit Output). Accuracy 0.011° (RMS). Data Output: Raw acceleration data / Tilt data / Temperature data at 5 - 500 Hz Output Rate. Power supply 5 to 36vDC (0.02A @ 12vDC)...
LPMS-INC1-RS232
LPMS-INC1-RS232: High Precision MEMS Dual Axis Inclinometer with LPBus connectivity. Inclinometers Measurement Range X: ±90°; Y: ±90°. Resolution: <0.001° (32-Bit Output). Accuracy 0.011° (RMS). Data Output: Raw acceleration data / Tilt data / Temperature data at 5 - 500 Hz Output Rate. Power supply 5 to 36vDC (0.025A @ 12vDC)...
LPMS-URS3
LPMS-URS3: 9-Axis IMU/AHRS/Motion Sensor with RS232 and USB connectivity. LPMS-URS3 includes 3-Axis Accelerometer, 3-Axis Gyroscope, 3-Axis Magnetometer Sensors. Data output format: Raw Data; Euler Angle; Quaternion @ up to 500Hz. Power supply 5 to 18vDC (RS232), 5vDC (USB). Dimensions: 34 x 34.5 x 15.7mm, weight: 17.6g. The LPMS-URS3 includes a..
MCDC4F
Blanking cap for miniature series MCIL type subsea connector, 4 pin female, to suit MCIL4M inline connector or MCBH4M bulkhead connectors. This item isn't available to purchase online but is normally held in stock. You can contact us directly to check availability and pricing. info@omni.uk.com..
MCV1-FO-ETH-SC-SI
Industrial Ethernet Fiber Media Converter, Singlemode, SC Connector, Ethernet 10/10BT, Fiber 100BT, Industrial and not flammable Case, up to 2Km...
MCV1-FO-ETH-ST-MU
Industrial Ethernet Fiber Media Converter, Multimode, ST Connector, Ethernet 10/10BT, Fiber 100BT, Industrial and not flammable Case, up to 2Km...
MF96021A
Nemo 96HD+ Multi-function panel mounted power meter suitable for single or 3 phase networks, 3 or 4-wires. Single-phase Input: 50-400V. Three-phase Input: 80-690V (phase-phase). Current Inputs 1A or 5A CTs. Meter has 4 slots for plug in modules. Auxiliary Power Supply: 80-265vAC/100-300vDC. Backlit LCD display with 8/12mm digits. Dimensions 96..
MIEX06122
MiniAir 6EX Mini vane anemometer. Sensing head 22mm diameter x 28mm, probe length 175mm. Air velocity range 0-20m/s with a 0-2V output. Accuracy ±1% of full scale, ±3% of reading. Power supply 9-24vDC Sensor is supplied with 20m cable to zener barrier housing. Operating range -10 to +80°C. Plastic sensing..
MiniAir20 Vane Anemometers
The MiniAir20 vane anemometers can be used to monitor air flows on the MC 4.0 Handheld Display. The probes are available with Micro, Mini and Macro heads and with flow range of 20m/s and 40m/s. The probes are designed to be automatically recognised by the MC4.0 display, which can set..
Mounting Kits for Solar Panels.
Mounting Kits designed for easy installation of BP/Ameresco and other framed solar modules. Kits include fixing poles for the solar panel and plates for securing the panel frames to solid surfaces or mounting poles. Securing plates are suitable for mounting poles with various diameters from 24mm up to 116mm with..
MPX-10BAR
MPX-10BAR Medium Pressure Calibrator, Range -1 to 10 Bar, Accuracy 0.05% (10 to 40°C). MPX calibrator is supplied with: Carry case; Spare battery; Y-coupler, Hose nipple; Connection nipple 1/4 inch BSP; Sealing rings (1/8 inch & 1/4 inch BSP); CrNi filter; Vacuum pump; K114A USB interface cable; Test certificate and..
MSR165-B8-A-N10006
MSR165 Datalogger, rechargeable lithium polymer battery 900 mAh. Integrated 3-axis digital accelerometer (13-bit resolution) with up to 1600 readings a second, range 15g. Unit comes with PC software and USB connection. Internal 3-Axis Acceleration Sensor. 15g Range. 4GB Formatted MicroSD Card...
MSR175 Shock Transportation Data Logger
The MSR175 is a miniature data logger designed for the high performance, high speed monitoring of conditions during transportation. The MSR175 is ideal for the identification and continuous documentation of external physical effects on cargo, such as shocks and jolts, temperature extremes, changes in humidity, light, or pressure. Two integrated..
MSR175-B16-T6-H3-P5-A-A5-L3
MSR175 Shock Transportation Data Logger. Design housing PC, encapsulated, IP 67. Up to 6,400 readings a second with 2 million reading memory. Suitable for up to 8 weeks recording period. Unit comes with MSR ShockViewer Basic Version software and USB connection. B16 -Standard Internal 230mAh LiPo Battery T6 - Temperature..
MSR175B54T6H3P5AA6L3PRO
MSR175Pro Shock Transportation Data Logger, Part No. MSR175B54T6H3P5AA6L3PRO. B54 – 3.6V, 5.8Ah SAFT LSH 14 Battery; T6 – Temperature Sensor. Range -20°C to +65°C; H3 – Humidity Sensor. Range 0 to 100%RH; P5 – Absolute Pressure Sensor. Range 0 to 2,000mBar; AA6 – Internal 3-Axis Acceleration Sensor. selectable ±10, ±20..
MSR83
MSR83 Temperature Data Logger with Display. Temperature Range: -30 to +70°C. Logging Interval: 1 minute up to 10 days. Internal Memory: 16,000 values. Replaceable CR 2023 Battery. Display shows current value, minimum, maximum and average value. Status LEDs to give a quick indication of any alarm conditions. Dimensions 51 x..
MTN/VM330D
MTN/VM330D High Performance Vibration Meter Kit. Meter will provide readings for vibrations, acceleration and displacement. The kit consists of a compact vibration meter, dual-output general purpose sensor, magnetic base and spike, a coiled cable with 4-pin Lumberg connector at each end, foam-lined protective carry case, universal battery chargers and calibration..
Multi-Point Air Velocity Probes & PA267 Differential Pressure Sensor.
A multi-point air velocity probes system using the PA267 differential pressure sensor and AV-EP or AV-MPS air velocity probes. This system can be used to ensure that recommended flow rates for public buildings and industrial plant are achieved. Suitable for flow ranges of 0 - 40m/s...
MX16 Easy Duo Gas Detectors with Control Panel
The MX16 Easy Duo is a combined MX16 Gas Controller and Single Gas Detector for a simple factory configured gas detection system. The 'Easy Duo' set includes an MX16 Controller pre-configured with an OLCT10N to detect Oxygen, Carbon Monoxide, Carbon Dioxide, Methane (0-4.4%Vol or 0-5%Vol) Hydrogen gas. The MX16 Controller..
