MCBH3M-SS
MCBH miniature bulkhead connector, suitable for 4000 metres WG, stainless steel with 3 male pins. This item isn't available to purchase online but is normally held in stock. You can contact us directly to check availability and pricing. info@omni.uk.com..
Meteon 2.0 Data Logger
The Meteon is a compact handheld display and data logger optimised for the PV related solar radiation measurement. It comes in a rugged carrying case that also offers room for a pyranometer and cable. It can accept up to 5 Smart pyranometers and one analogue radiometer, plus temperature sensor. A..
MIEX06254
MiniAir 6EX Mini vane anemometer. Sensing head 22mm diameter x 28mm, probe length 175mm. Air velocity range 0-40m/s with a 0-2V output. Accuracy ±1% of full scale, ±3% of reading. Power supply 9-24vDC Sensor is supplied with 20m cable to zener barrier housing. Operating range -10 to +80°C. Plastic sensing..
Modbus RTU Temperature & Humidity Sensor
The TSH300 is a Modbus RTU Temperature & Humidity Sensor, designed for accurate monitoring of temperatures in the range of -20 to +60°C. Up to 32 sensors can be connected back to a Modbus Master device. It features two RJ45 connectors for easy daisy-chaining on an RS485 Modbus, making it..
MTN/1185IC
MTN/1185IC Series Hazardous Area Approved velocity transducer with 5m of stainless steel overbraided cable. Robust Stainless Steel Construction with a 2-wire 4-20mA output. Measurement ranges: 0-10, 0-20, 0-25, 0-50, 0-100mm/sec. Power supply 12-32vDC. Frequency response 2Hz to 1kHz. Various mounting options. ATEX Approved Ex ia IIC T6 Ga, Ex ia..
MTW-PULSE-OPTION-K=100
Pulse output option suitable for 25, 32 & 40mm MTW hot water flow meters. One pulse for each 100Ltr...
MX16-N-002-1-0-0
Easy Duo MX16 Gas Detection Controller with OLCT10N for CH4 (Methane) fitted with 10m cable. Range 0-4.4% Volume. RS485 Modbus Comms, 2 Alarm levels (Al1 and Al2) + 1 fault, with Dry Contact Relays. LCD back-lit display. IP55 Enclosure with 3 x M16 and 2 x M20 cable glands. Dimensions..
OLCT10-002
OLCT10 Fixed Gas Detector for Methane (CH4), Range 0-4.4% Volume. Output: 4-20mA. Response Time:<10 Seconds. Power supply: 15-30vDC, consumption 100mA max. Operating temperature: -10 to +60°C. Life span: 4 years. Plastic housing, 118 x 157 x 60mm, IP65. ATEX Certification: II 3G, Ex nA IIC T4...
OLCT10-501
OLCT10 Fixed Gas Detector for R22 Refrigerant Gas Range 0-2000ppm. Output 4-20mA. Power supply 15-30vDC, consumption 100mA max. Operating temperature -10 to +60°C. Life span 24 months. Plastic housing, 118 x 157 x 60mm, IP65...
OMEGA-PULSE-OPTION-K=1000
Pulse output option for Omega water meters 1,000Ltr/pulse..
PB-5001-3M
Standard Thermistor Probe with moulded handle and connector (IP68 rated). The stainless steel probe is 150mm long and 5mm in diameter with a 3m cable. Temperature range -40 to 125°C with a 15 second response time in water...
QI-60/5-1
Current Transformer 60A, DIN rail mounting, 20mm hole, 5A Secondary..
QT-C-112
SafEye Quasar 901 Transmitter Unit. Range 7-20m. Warm up time: 30 seconds. Xenon Flash Infrared Source, emits IR radiation pulse at a rate of 2 pulse per second. Pulse width of 5-10µsec. ATEX/IECEx Approved Ex d e ib [ib Gb] IIB+H2 T4 Gb, Ex tb IIIC T135°C Db. IP66 and..
RTR502B
RTR502B Remote Data Logger with external thermistor sensor, Ref TR-5106. Measurement Range: -60 to +155°C, Accuracy ±0.3°C (-20 to +80°C), Resolution 0.1°C. Response Time 80 Secs (t90% in air). Internal Memory 16,000 Readings, Logging Interval: 1, 2, 5, 10, 15, 20, 30 sec. or 1, 2, 5, 10, 15, 20,..
SUBSEA-SW3-CRE
Subsea logger schedule switch assembly comprising of square mounting plate 200 x 200 x 8mm, 316 stainless steel, with rotating switch bar (190 x 50 x 25mm), fitted with 2 permanent magnets. Subsea housing with proximity switch mounted behind the square switch assembly fitted with 1 x CRE BRA03F090018 3..
SW10026.4
Steel Pitot Tube for measuring static and dynamic pressure in air flows. 5mm diameter tube with 400mm probe length. Suitable for temperatures up to 350°C..
TR-5106
Fluoropolymer coated temperature sensor for TR42 . Flexible probe, 600mm x 2.2mm diameter, measurement range -60 to +155°C. response time 80 seconds in air, 7 seconds in water. Accuracy Avg. ± 0.3°C at -20 to 80°C Avg. ± 0.5°C at -40 to -20°C, 80 to 110°C. Avg. ± 1.0°C at..
TT-OR-CVO-C
TT-OR-CVO-C Outside Air Temperature Sensor with a PTFE radiation shield suitable for monitoring temperature in an external environment. Housing is a grey, IP65, PC/GF (Halogen free, flame retardant & UV stablised) with a PT100 temperature sensing elements housed in a 40 x 16mm diameter radiation shield. Selectable 4-20mA or 0-10vDC..
TX2-14021
Tango TX2 Two Gas Detector for Carbon Monoxide (CO), Range 0-1000 ppm in 1ppm increments & Nitrogen Dioxide (NO2), Range 0-150 ppm in 0.1ppm increments. Alarms: Audible 100dB, vibration and three strobe-emitting visual LEDs. Internal logging for 3 months at 10 second interval plus 60 alarm events. The replaceable internal..
WC30CO2B
CTX 300 Fixed Gas Detector. Infrared Carbon Dioxide (CO2) Cell, Range 0-5%. Accuracy ±2% (% at PA full scale), response time less than 20 seconds. Operating temperature -40 to +50°C. Life span 60 months...
WP-SDC-H-PULSE-OPTION-K=1000
Pulse Output Option for WP-SDC Hot Water Meters 1 m³h/Pulse, or 1,000Ltr/pulse..
WSERIAL-3005-N
wSerial Wireless Node, with 4 Aalogue Inputs (0-10vDC or 4-20mA), 4 Digital Inputs, 2 Digital Outputs (open collector), Nodes provide serial data back to a wSerial Concentrator via a MESH Network. Power Supply 10-30vDC. Operating Temperature -15 to +65°C. DIN rail mounting. 1 x RS232/RS485/USB transparent serial port, supports MODBUS..
PR 5332 2-Wire Programmable RTD Transmitter
The PR 5332 is designed to convert 2-, 3-, or 4-Wire RTD and linear resistance measurements to a linearised 4-20mA signal. The PR 5332 can handle inputs from PT100, PT1000 and Ni100, Ni1000 sensors and resistances up to 5,000Ω. The PR 5332 is engineered for superior performance, featuring an impressive..
333711
1.44Mb, 3.5 inch MS-DOS compatible disk drive logging storage package, comes complete with PC Software. This internal storage can also be used to store 16 additional settings files independent from a PC...
