CGR4 Pyrgeometer
The CGR4 is a pyrgeometer, designed for top level solar radiation monitoring networks such as the Baseline Surface Radiation Network (BSRN) of the World Meteorological Organisation for the meteorological measurements of downward atmospheric longwave radiation. The CGR4 uses a thermopile detectors and has a sensitivity of 5 to 15V/W/m in..
CHAR-INLINE-12V
Switch mode bench-top charger unit for lead acid batteries. Capacity up to 12Ah. Charge Current 4A. Input Voltage 100 to 264 vAC. Output Voltage 12vDC, Output Power Max 14.7W. 2 pin IEC 320 connection. Mains lead available separately..
CMC-141
CMC-141 Multi-Channel Display/Data Logger. 5.7" touchscreen display for digital, bar graph and graphical display of process values of up to 72 analogue inputs, 36 relay/SSR outputs and 18 current outputs. An RS485 Modbus RTU interface allows for integration into local Modbus networks. Power supply options of 19-50vDC and 85-260vAC. Internal..
CMC-99
CMC-99 Multi-Channel Display & Data Logger. 3.5" touchscreen display for digital, bar graph and graphical display of process values of up to 48 analogue inputs, 16 relay/SSR outputs and 8 current outputs. An RS485 Modbus RTU interface allows for integration into local Modbus networks. Power supply options of 19-50vDC and..
CMC-N16
The CMC-N16 is an CMC Multi-Channel Display & Data Logger in an IP65 enclosure. 3.5" touchscreen display for digital, bar graph and graphical display of process values of up to 4 analogue inputs, 4 relay/SSR outputs and 4 current outputs. An RS485 Modbus RTU interface allows for integration into local..
CO2-DISPLAY
CO2 Multi-Parameter Display with an integrated sensors. Wall or bench-top mounting options. Measuring range: -20 to +60°C & 0 to 100%RH, 0 to 5000ppm. The CO2 Display has an internal memory for up to 19,500 data points CO2 Display is powered by a 12V AC Mains Adaptor. IP30 housing, dimensions..
Colinear GSM Antenna
Colinear GSM frequency antenna for wall mounting with an extra strength reinforced bracket. The COLGSM is an omni-directional antenna suitable for use with most GSM & GPRS devices with a radio band frequency from 868MHz to 915MHz. Standard options are 5 and 10m of cable with an SMA connector. Other..
COMPASS-A4020-35
Compass sensor, with 0-5V output for 0-360 degrees, power supply 7-15vDC at 60mA, operating temperature -20 to +65°C. Tilt compensation to 35°...
CRYO-TEMP
Cryo-Temp Ultra Low Temperature Data Logger. Operating temperature range -86 to +35 C...
CS150 Conductivity Probes
The CS150 12mm Graphite Contacting Conductivity Sensor is suitable for both laboratory and light industrial applications. Sensors can be mounted in-line via ½" or ¶ó" NPT mounting threads, or fully submerged. The sensor can be configured to meet your own requirements with temperature compensation, options for cell constants from 0.1/cm..
CS150 Conductivity Probes
Epoxy Body With Graphite Contacting Conductivity Sensor. Dimensions: 152 mm x 12mm Diameter. Operating Temperature Range 0-70°C, Maximum Pressure 7.5 Bar..
CSD3 Sunshine Duration Sensor
The CSD 3 is used for monitoring sunshine duration and automates the process previously undertaken by a traditional Campbell-Stokes recorder. The CSD 3 measures solar radiation through a high quality glass tube. It has no moving parts and uses 3 photo-diodes with specially designed diffusers to make an analogue calculation..
CTH Current Sensor
Ranges 10/20/30/40/50/100 Amps DC, available outputs 0-5v, 0-10v, 4-20mA, power supply 12/24/48/110 vDC or 230VAC. Type 1 & 2 Solid Core...
CTH-20A-5V-24VDC
CTH type 5 DC current sensor range 0-20 AMPS DC, output 0-5v DC, power supply 24v DC, with 21mm diameter hole...
Datataker DT80 Universal Input Data Logger
The Datataker DT80 Series 4 data loggers are a standalone data logger with 5-15 analogue inputs (up to 10 isolated inputs), 8 digital I/Os and 2 serial ports. CEM-20 modules allow the analogue inputs to increase to up to 300 channels. Internal memory for up to 10 million readings, expandable..
DBB S Beam – Bi-directional Load Cell
The DBB series of loadcells are an S beam, bi-directional load cell suitable for tension and compression applications. Loadcells are available with a bi-directional range of 50Kgf up to 10,000Kgf with a standard 2mV/V output and accuracy of 0.03%. The smaller DBBE is an encapsulated cell sealed to IP67. Units..
DBBSS/TSF Axial Force and Load Cell
DBBSS/TSF Series - Combined Axial Force & Torque Load Cell. Ranges 1kN to 250kN, . Load cells are constructed from Stainless Steel and has a IP65 rating..
DBCL Load Cell
DBCL In-Line - Bi-directional Load Cell. Ranges from 1 Tonne to 100 Tonnes, Output 1.5mV/V, accuracy 0.2%. DBCL load cell is a stainless steel construction with an IP66 rating. Submersible option available with IP67 rating...
DC Voltage Transducers
DIN rail mounted DC voltage transducer with isolated DC outputs, accuracy ±0.25%, adjustable span and zero...
DC-DC-CONV-18-36V-5V
Traco Power DC-DC Converter. Input Voltage: 18-36vDC. Output Voltage 5vDC. Output Power: 3 Watts (600mA). Ideal for powering sensors requiring a 5V stabilised supply...
DCX-22VG Water Level Loggers
DCX-22VG water level data logger, range 0-10 up to 0-100 metres WG ( vented ), accuracy 0.05% of full scale. Resolution max. 0,0025 %FS. Battery life 10 years. Operating temperature -10 to +40 C...
DE-211
DE-211 Serial to LAN equipment 230Vac UK PSU included, RJ45 (LAN) to DB25 (serial) connectors...
DER Current Shunt
DER Type, Standard DIN DC Current Shunt. Accuracy class 0.5. Provides a 60mV proportional voltage output for DC current ranges from 1 amp to 10,000 amps..
DFM Series Flow Meter
All plastic Variable Area Flow Meter...
