BETA-MJ-SDC/H(5R)20
BETA Multi-Jet Hot Water Flow Meter. Pipe diameter 20mm with 3/4 inch BSP threaded connections. Flow range: Q3 4m³/hr. Epoxy coated Brass body suitable for up to water up to 90°C. All BETA Flow meters are supplied with nuts, tails and washers, plus come prepared for a pulse output of..
BL-1D-SET
HygroLog BL-1D datalogger with an integrated temperature, humidity and barometric pressure sensors and LED display. The BL-1D has an internal memory for up to 64,000 data points with adjustable log intervals (30secs to 24Hrs). Measuring range: -20 to +70°C, 0 to 100%RH and 300 to 1100 hPa. Accuracy ±0.3°C, ±3%RH..
C67411
GT-41 Multi-Function Gas Detector Kit for CH4 and O2 gas detection. Methane (CH4), Range 0 to 10,000ppm & 0-100% LEL or Volume. Oxygen (O2), Range 0 to 25%. Highly visible flashing LEDs on display panel. 80dBA Sounder, typically 85 dBA @12 in. ATEX/IEC Certification: Ex ia d IIB T3. CSA..
C67F51
GT-Fire 51 Multi-Function Gas Detector Kit for Flammable Hydrocarbon Gas Detection. Methane (CH4) Range 0 to 10,000ppm and 0-100% LEL. Highly visible flashing LEDs on display panel. 80dBA Sounder, typically 85 dBA @12 in. ATEX Certification: SIRA05 ATEX II 2G EEx iad IIB T3. IECEx Certification: Ex ia d IIB..
CA-01/18
Rutland 914i Wind Turbine, with Horizontal-Axis Wind Turbine (HAWT) Design. Power Output: 24 Watts (0.8A) @ 5m/s, 262 Watts (9.4A) @ 15m/s. Voltage Output: 24V. Cut in Speed: 3m/s, Turbine Diameter: 910mm, Turning Radius: 557mm. Weight: 11.58Kg (net)...
CA-02/05
Rutland FM910-4 Wind Turbine, with Horizontal-Axis Wind Turbine (HAWT) Design. Power Output: 19 Watts (0.7A) @ 5m/s, 155 Watts (5.6A) @ 15m/s. Voltage Output: 24V. Cut in Speed: 3m/s, Turbine Diameter: 910mm, Turning Radius: 794mm. Weight: 13.1Kg (net)...
CA-03/02+CA-04/15
Rutland FM1803 Wind Turbine, Horizontal-Axis Wind Turbine (HAWT) Design, with Furlmatic Operation. Power Output: 52 Watts (1.88A) @ 5m/s, 840 Watts (30.43A) @ 15m/s. Voltage Output: 24V. Cut in Speed: 3m/s, Turbine Diameter: 1800mm, Turning Radius: 1145mm. Weight: 29.2Kg (net), Supplied with Marlec MPC2 24V Charge Controller with temperature sensor..
CA-06/02
Rutland 1200M Wind Turbine 24V, Horizontal-Axis Wind Turbine (HAWT) Design, with Furlmatic Operation. Power Output: 40 Watts (1.45A) @ 5m/s, 483 Watts (17.76A) @ 15m/s. Voltage Output: 24V. Cut in Speed: 2.5m/s, Turbine Diameter: 1200mm, Turning Radius: 620mm. Weight: 7.8Kg (net)...
CA-06/05
Rutland 1200T Wind Turbine 24V, Horizontal-Axis Wind Turbine (HAWT) Design, with Furlmatic Operation. Power Output: 40 Watts (1.45A) @ 5m/s, 483 Watts (17.5A) @ 15m/s. Voltage Output: 24V. Cut in Speed: 2.5m/s, Turbine Diameter: 1200mm, Turning Radius: 620mm. Weight: 7.8Kg (net)...
CA-10/152
Ameresco 20J Photovoltaic Solar Panel. Rated Power 20W at a Nominal Voltage 12V. Universal frame with an accessible IP65 junction box with 4 screw terminal connection block for cable connection allowing easier module interconnections for off-grid applications. Dimension 452 x 502 x 50mm. Weight 3.00Kg...
CA-10/202
25W SunWare Rectangle Photovoltaic Solar Panel, SW-20163. Charging current of up to 1.44A at a nominal 12V (Max 20.60V). Light-weight mounting plate made from Aluminium sandwich, powder-coated white with 6 drill holes for mounting panel. Panel may also be secured using glue or SunWare fixing clips (available separately). Front junction..
CA-10/453A
35W SpectraLite SemiFlex Solar Panel. Peak Output 35 Watts. Mono Crystalline Solar Cells with standard ETFE non-slip coating. 4 Corner eyelets for safe and easy installation. Semi-flexible modules with a sealed junction box with blocking diode and 3m of output cable. Dimension 600 x 365 x 4mm. Gross weight 1.35Kg...
CA-12/0020
Solar Mounting Kit for a 20W Ameresco Solar Panel U-bolts are required for pole mounting..
CA-12/02
Marine Stays Kit for Rutland 914 Wind Chargers. This marine mounting kit includes 2 x 1.2m length stainless steel tubes (45mm diameter), tube joiner & fasteners, deck brackets, guy brackets & fasteners, etc (does not include deck through bolts). Tubes can be cut to size if required with 4 end..
CA-17/04
Sealed Gel Battery. Storage Capacity 12Ah, Output 12V. Dimensions: 150 x 97 x 100mm. Weight: 4Kg..
CA-17/21
Absorbed Glass Matt (AGM) Battery. Storage Capacity 38Ah, Output 12V. Dimensions: 195 x 130 x 160mm. Weight: 10.9Kg..
CE4DT06A4
Conto D4-Pd KWH meter with single or three phase input for direct connection up to 63 amps, DIN rail mount, with RS485 MODBUS output...
CE4ST14A4/770
Multifunction power metre for single or three phase supplies, 1 & 5 Amp CT input with MODBUS RS485 output...
cLAN Ethernet TCP/IP Data Logger
The cLAN data logger includes an Ethernet interface to allow for data transfer via TCP/IP. The cLAN unit comes complete with an embedded Modbus Master for I/O expansion. Two versions of the cLAN are available, CLAN-1520-XF has 2 serial ports allowing Modbus (Master or Slave) or transparent serial access from..
COMPASS-A4020-45
Compass sensor, with 0-5V output for 0-360 degrees, power supply 7-15vDC at 60mA, operating temperature -20 to +65°C. Tilt compensation to 45°...
Conto D4-Sh – Multifunction Power Meters
The Conto D4-SH multifunction power meter is suitable for monitoring single and three phase supplies for current, phase to phase and phase to neutral voltage and kWh consumption. It offers a pulse output for kWh measurement or Modbus RS485..
CTH-30A-5V-24VDC
CTH type 5 DC current sensor range 0-30 AMPS DC, output 0-5v DC, power supply 24v DC, with 21mm diameter hole...
Datataker DT82E Environmental Logger
The Datataker DT82E is a smart data logger designed especially for environmental monitoring. The DT82E is a robust, low power data logger featuring USB memory stick support, 18-bit resolution, extensive communications capabilities and built-in display. The DT82E also supports SDI-12 inputs, allowing it to be used with various weather station..
DBBSM S Beam – Bi-directional Load Cell
The DBBSM series loadcells are a miniature S beam, bi-directional load cell suitable for tension and compression applications. Loadcells are available with a bi-directional range of 1Kgf up to 30,000Kgf with a standard 2.7mV/V (2mV/V above 10,000Kgf) output and accuracy of 0.03%. Units can be supplied with suitable inline amplifiers..
