WP2115
WP Series - Standard Industrial Weighing Platform in Mild Steel. Platform dimensions 2100 x 1500mm. Capacity 0-300 to 0-3000 (Kg). Dunbar top plate with hammer spray paint finish. Fitted with four stainless steel OIML-approved load cells sealed to IP67 and self absorbing, heavy duty rubber mounting feet...
WP2115-RAMP
WP Series - Platform Ramp in Mild Steel for Weighing platform (2100 x 1500mm). Fits to smallest side. Priced per ramp...
WR3 Remote Mounted MID Approved Heat Meter
Minocal WR3 Remote Mounted Heat Meters with 2 x 3m PT500 temperature probe and pockets. Suitable for heating applications with a temperature range of 10 to 90°C. Units supplied with a 6 yr battery powered Heat Integrator LCD display unit...
wRemote Wireless Data Acquisition System
wRemote is a 2.4GHz Zigbee wireless mesh system for remote data acquisition of digital and analogue signals from sensors, switches and relays, and also MODBUS data from PLC s, power meters and other MODBUS devices. Data can be wirelessly collected from many remote nodes and delivered to a central colector..
wRemote-3004-ND
wRemote wireless remote node, with 2 analogue 0-10 or 4-20mA, 4 digital inputs, 2 digital outputs ( open collector ) Power supply 10-30vDC, operating temperature -5 to +65°C, DIN rail mounting. 1 x RS232/RS485 serial port, MODBUS protocol RTU/ASCII. 2.4GHz Zigbee radio communications, maximum range 2Km line of sight. Maximum..
WREMOTE-3106-BP
wRemote wireless remote node, with 4 analogue 0-10vDC or 4-20mA inputs and 4 digital/count inputs. Power supply internal battery. 2.4GHz ZigBee radio communications, maximum range 2KM line of sight. Housed in an IP68 enclosure. Low powered node, which will NOT relay signal from other nodes in a Mesh network...
WS400 Weather Station
The WS400 weather station is a compact weather station for measuring Air Temperature, Relative Humidity, Air Pressure and Precipitation intensity, type and quantity. Outputs are in RS485 in the following protocols: ASCII; UMB; SDI-12; and ModBus. Available with low-power setting for remote stations with solar power and can be integrated..
WS400-UMB
WS400 Compact Weather Station, EU/USA version, for measuring Air Temperature, Relative Humidity, Air Pressure and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: EU/USA version has FCC ID: UF9IPS137, Lower Frequency in MHz: 24125.0, Upper Frequency in MHz: 24125.0..
WS400-UMB-UK
WS400 Compact Weather Station, UK version, for measuring Air Temperature, Relative Humidity, Air Pressure and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: UK version has FCC ID: UF9IPS149, Lower Frequency in MHz: 2435.0, Upper Frequency in MHz: 2475.0..
WS501 Weather Station
The WS501 weather station is a compact weather station for measuring Wind Speed & Direction, Air Temperature, Relative Humidity, Air Pressure and Solar Radiation. Outputs are in RS485 in the following protocols: ASCII; UMB; SDI-12; and ModBus. Available with low-power setting for remote stations with solar power and can be..
WS501-UMB
WS501 Compact Weather Station for measuring Wind Speed, Wind Direction, Air Temperature, Relative Humidity, Air Pressure and Solar Radiation. Output via RS485, in ASCII, UMB, SDI-12 and ModBus...
WS600 Weather Station
The WS600 weather station is a compact weather station for measuring Air Temperature, Relative Humidity, Air Pressure, Wind Speed & Direction and Precipitation intensity, type and quantity. Outputs are in RS485 in the following protocols: ASCII; UMB; SDI-12; and ModBus. Available with low-power setting for remote stations with solar power..
WS600-UMB
WS600 Compact Weather Station, EU/USA version, for measuring Air Temperature, Relative Humidity, Air Pressure, Wind Speed & Direction and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: EU/USA version has FCC ID: UF9IPS137, Lower Frequency in MHz: 24125.0, Upper Frequency in..
WS600-UMB-UK
WS600 Compact Weather Station, UK version, for measuring Air Temperature, Relative Humidity, Air Pressure, Wind Speed & Direction and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: UK version has FCC ID: UF9IPS149, Lower Frequency in MHz: 2435.0, Upper Frequency in..
WSerial 2.4GHz Wireless Radio
The wSerial provides a serial network over a Mesh Network to provide not only point to point but also point to multiple points. A Concentrator unit provides the main interface unit between your SCADA, PLC or HMI system and the Mesh network of remote Node units. Each unit has 1..
WTP-100
WTP-100 Wireless communications link between XR440/XR5 data logger and PC. Transmission range up to 30m indoor and 100m outdoor. Supplied with battery cable and AC power suppy for remote module with US plug...
WTP-100 Wireless Communications Link
The Pace WTP-100 is a miniature wireless transceiver pair that replaces the cable connection between the XR400 and XR5 data loggers and a PC. The WTP-100 consists of two wireless modules. One module plugs into a PC's USB port and the other module connects to the IC209 cable connected to..
WTP-100-EXP
WTP-100 Wireless communications link between XR440/XR5 data logger and PC. Transmission range up to 30m indoor and 100m outdoor. Supplied with battery cable and AC power suppy for remote module with UK, EU and Australian plugs...
WTunnel 2.4GHz Wireless ZigBee Radio System
The wTunnel radio system provides a point to point wireless connection between two units. Each unit has 1 Serial RS232/485/USB port, 2 Analogue Inputs (0-10 and 4-20mA), 2 Digital Inputs and 2 Digital Outputs. Serial ports will operate as transparent serial port allowing two serial devices to connect over the..
X005-425
X005-425 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 4-20mA output. Tri-port isolation between power supply,..
X005-426
X005-426 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 20-4mA output. Tri-port isolation between power supply,..
X005-545
X005-545 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 0.5-9.5vDC output. Tri-port isolation between power supply,..
X005-546
X005-546 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 9.5-0.5vDC output. Tri-port isolation between power supply,..
X101 Intrinsically Safe Linear Position Sensor
The X101 is an ATEX approved, Intrinsically Safe stand alone linear position sensor that is suitable for use in hazardous areas with potentially explosive gases or vapours. The X101 units are supplied with a ratiometric 0.5-4.5vDC output, calibrated to any travel distance between 50 and 600mm, and full EMC protection..
