NEMO 96HD Additional Modules
A selection of NEMO 96HD modules for use with the Nemo 96HD Multi-function power meters. These modules provide additional output and communications options to the power meters..
RODENDM12X1.75-DDE
Rod End Bearing to align extraneous forces through the principle axis of a load cell. M12 x 1.75 Female Right-hand Thread Construction: Hard Chromium/PTFE composite/Elgoglide sliding contact surface, with Zinc plating for corrosion resistance. Rod Eye 12mm diameter. Designation: GIR12 UK..
RODENDM12X1.75-DDEN
Rod End Bearing to align extraneous forces through the principle axis of a load cell. M12 x 1.75 Female Right-hand Thread Construction: Stainless Steel with radial spherical plain bearings and PTFE composite sliding contact surface. Rod Eye 12mm diameter. Designation: GIRSW-12RR-316..
5200-15S-BR
Set of two blocking rings for resealing pipework when flow meters are removed. Suitable for CDI-5200-15S flow meters..
PIC-3150
Pulse Input Cable for RTR505B(L), TR55i-P and RTR505-P(L) Remote Units. Cable includes two M3.5 Crimp Terminals. Pulse Count Range: 0-9999 resetting, Pulse Rate (per interval): up to 61439. Module Operating Environment: Temperature -40 to 80°C, Humidity 90%RH or less (no condensation)..
RODENDM16X2.0
Rod End Bearing to align extraneous forces through the principle axis of a load cell. M16 x 2.0 Male Right-hand Thread Construction: Hard Chromium/PTFE composite/Elgoglide sliding contact surface, with Zinc plating for corrosion resistance. Rod Eye 17mm diameter. Designation: GAR17 UK..
SC1500A
SC1500A Split core, self powered, AC current sensor. Current range 0-1,500 Amps, output 0-5vDC. Accuracy ±1% of reading from 10% to 100% of full scale. Dimensions 5.4" x 4.7" x 1.25" with a 4" square window and 8ft signal cable. Operating temperature -20 to +55°C...
Field Mounted Modbus Modules
Custom enclosures providing a robust, "plug-and-play" solution for remote signal collection and relay control. Built to your exact specifications, these weatherproof units integrate I/O modules into a reliable RS485 Modbus network using simple twisted-pair cabling. Whether you need to monitor analogue sensors on a solar farm, track pulse counts for..
NS500 Low Flow Pelton Wheel Flow Meter
The NS500 turbine flow meter operates on the Pelton wheel principle allowing the flow meter to be used for low flow rate applications with low viscosity fluids. Flow meters are available with flanged or BSP couplings for high pressure hydraulic work. Flow ranges from 0.18 - 1.8 ltrs/min to 1.3..
OMNI-SUBSEA-ULTRASONIC-04-ANSI150-AL
Omni Instruments Subsea Ultrasonic flow meter suitable for measuring the flow of clean fluids such as sea water, oil, or chemicals in subsea pipelines. For 4 inch pipe diameter with ANSI150 4 inch flanges and anodised aluminium body. With 4-20mA output for flow rate. Micro Subcon connecter for power and..
OmniAmp Inline RTD Signal Converter
The OmniAmp inline temperature transmitter converts PT1000 or PT100 RTD inputs to a 4-20mA or MODBUS RS485 signal output...
OmniAmp Inline RTD Transmitter
The OmniAmp inline temperature transmitter converts PT1000 or PT100 RTD inputs to a 4-20mA or Modbus RS485 signal output...
Subsea Ultrasonic Flow Meter
The Omni Instruments Subsea Ultrasonic flow meter is suitable for measuring the flow of clean fluids such as sea water, oil, or chemicals in subsea pipelines. Units are available for pipe diameters from 1 inch to 5 inch with flange or threaded connections in durable 316 Stainless Steel or a..
5200-15C-BR
Set of two blocking rings for resealing pipework when flow meters are removed. Suitable for CDI-5200-15C flow meters..
NT11-5-50-1/2BSP
NT11 turbine flowmeter as above, 1/2 inch BSP male threads, range 5 -50 l/min...
NT13-8-80-3/4BSP
NT13 turbine flowmeter as above, 3/4 inch BSP male threads, range 8 -80 l/min...
NT19-15-150-1BSP
NT19 turbine flowmeter as above, 1 inch BSP male threads, range 15 -150 l/min...
NT24-25-250-1BSP
NT24 turbine flowmeter as above, 1 inch BSP male threads, range 25 -250 l/min...
NT3-0.5-5-3/8BSP
NT3 turbine flowmeter, all st. st. body and wetted parts, 3/8 inch BSP male threads, AC O/P 50 - 800 mV peak to peak, frequency proportional to flow. Range 0.5 -5l/min. Accuracy 0.5% FSD. Operating temperature -30 to +150 deg C. Operating pressure to 350 bar ( 5000 PSI )...
NT32-45-450-11/4BSP
NT32 turbine flowmeter as above, 1 1/4 inch BSP male threads, range 45 -450 l/min...
NT38-65-650-11/2BSP
NT38 turbine flowmeter as above, 1 1/2 inch BSP male threads, range 65 -650 l/min...
NT48-110-1100-2BSP
NT48 turbine flowmeter as above, 2 inch BSP male threads, range 110 -1100 l/min...
NT5-1.2-10-1/2BSP
NT5 turbine flowmeter as above, 1/2 inch BSP male threads, range 1.2 -10 l/min...
NT65-200-2000-3BSP
NT65 turbine flowmeter as above, 3 inch BSP male threads, range 200 - 2000 l/min...
