Home / Level & Distance Sensors / Toughsonic-100 Ultrasonic Sensors / ToughSonic TS-100.50 Sensor
ToughSonic TS-100.50 Sensor

ToughSonic TS-100.50 Sensor

The ToughSonic TS-100.50 Sensor uses an ultrasonic signal for non-contact measurements of liquid level and object detection in demanding industrial environments. Maximum Range 0-15.2m (0-50 Feet), optimal range 0-10m. Housed in a marine grade 316 Stainless Steel, epoxy potted housing it is built to withstand harsh, wet, or outdoor conditions and temperatures from -40°C to +70°C. Connectivity options include flexible 0–10 VDC and 4–20 mA analogue outputs as well as serial communications.

View Options

Need help finding the right product?

CONTACT US

Downloads

Datasheet

ToughSonic TS-100.50 Sensor

Product

Ref

Price

Product Description

ToughSonic Remote 50 RS232

U50-REMOTE-232

£732.30

ToughSonic Remote 50 Ultrasonic Level Sensor, with RS232 serial Modbus RTU interface. Optimal range 305mm to 9.1m, max range 15.2m. Power Supply 10-30vDC (typical 30mA @ 24vDC). Marine grade 316 Stainless Steel IP68 housing with 2.3 inch clamp mounting and 2m cable. Operating temperature -40 to +70°C, 0-100%RH. Dimensions 59mm diameter x 122mm long.
MORE INFO
Add to basket
ToughSonic Remote 50 RS485

U50-REMOTE-485

£732.30

ToughSonic Remote 50 Ultrasonic Level Sensor, with RS485 serial Modbus RTU interface. Optimal range 305mm to 9.1m, max range 15.2m. Power Supply 10-30vDC (typical 30mA @ 24vDC). Marine grade 316 Stainless Steel IP68 housing with 2.3 inch clamp mounting and 2m cable. Operating temperature -40 to +70°C, 0-100%RH. Dimensions 59mm diameter x 122mm long.
MORE INFO
Add to basket

TSPC-21S-232

£786.63

Standard ToughSonic 50 Ultrasonic Level Sensor. Optimal range 305mm to 10m, max range 15.2m. Power Supply 10-30vDC with programmable outputs between 0-10vDC and 4-20mA, plus NPN & PNP switch outputs (configurable as sinking or sourcing) and RS232 serial interface. Marine grade 316 Stainless Steel IP68 smooth housing for easy clamping and 2m cable. Operating temperature -40 to +70°C, 0-100%RH. Dimensions 59mm diameter x 122mm long. UA-MB-SS or UA-CLIC mounting accessories available separately.
MORE INFO
Add to basket

TSPC-21S-485

£786.63

Standard ToughSonic 50 Ultrasonic Level Sensor. Optimal range 305mm to 10m, max range 15.2m. Power Supply 10-30vDC with programmable outputs between 0-10vDC and 4-20mA, plus NPN & PNP switch outputs (configurable as sinking or sourcing) and RS485 serial interface. Marine grade 316 Stainless Steel IP68 smooth housing for easy clamping and 2m cable. Operating temperature -40 to +70°C, 0-100%RH. Dimensions 59mm diameter x 122mm long. UA-MB-SS or UA-CLIC mounting accessories available separately.
MORE INFO
Add to basket

TSPC-PROG

£20.00

ToughSonic level & distance sensor programming to the applications specifications. Price is for setting the analogue 4-20mA/0-10V and PNP/NPN outputs to the desired ranges.
MORE INFO
Add to basket
