Description

Features

• Capable of performing thickness measurements on a wide range of materials including metals (such as steel, cast iron, aluminum, copper and so on), plastic, ceramics, composites, epoxy, glass and other ultrasonic well-conductive materials.
Sealed metal case, delicate design, special design for defense against bad site environment, it can anti vibration, shock and electromagnetic interference.
• With HD colourful LCD display and intelligent operation, it can display the measurement results intuitively and provide a good experience to user.
• With two thickness measurement modes: Pulse-Echo mode and Echo-Echo mode, it can measure the thickness through the coating without the coating being removed.
• With large storage capacity and lower power design, it can standby super long time without power.
• Attach with USB data proceeding software, it can connect with PC for data’s analysis, storage and printing.
• Capable for compatibility with a variety of probes with different frequency.
• With high accuracy and high resolution, it can support 0.001 display resolution.
• With probe-zero calibration and two point calibration functions, it can correct the system error automatically.
• Equipped with narrow impulse composite crystal high accuracy probe, it has small dead zone and excellent performance.
• With high brightness E.L. backlight display, it is convenient for using in dim light environment.
• Support communication with Bluetooth printer on site, more convenient for service.
• Auto alarm when exceeding the measuring range.
• With auto sleep, auto shutdown and other power saving functions as well as battery rest capacity indicating function.

Specifications
