Product Applications – LEO2EI-300BAR-1/4″BSP
High-Pressure Cleaning
Industrial high-pressure cleaning systems frequently operate at pressures reaching 300 bar. In environments where flammable gases are present, or in designated hazardous areas, robust and reliable pressure monitoring is essential for safe and effective cleaning operations.
Compressed Gases
Numerous industries rely on compressed gases, including hazardous varieties used in welding, manufacturing, and laboratory settings. The LEO2EI-300BAR provides crucial monitoring capabilities for storage cylinders, refilling procedures, and supply lines within industrial processes, ensuring safe handling of these gases.
Fire-Suppression Systems
Many hazardous areas are equipped with high-pressure fire suppression systems designed for rapid deployment of suppression agents. In such applications, the LEO2EI-300BAR offers a clear and immediate visual display of system pressures, facilitating quick assessment and ensuring system readiness
Features
- Pressure range of 0-300 Bar
- Display read out can be changed to 7 different units of measure
- Display updated twice a second for a rapid response
- Front Buttons allow switching between Min or Max readings
- Swivel Adapter allows for optimal positioning, even under pressure
- Rubber Cover is available to protect the gauge from knocks or damage
Specifications
| Pressure Ranges | This unit | Other Stocked Ranges | Non-Stocked Ranges |
| 0…300 Bar | -1…3 Bar -1…30 Bar 0…700 Bar |
-1…10 Bar -1…100 Bar |
|
| Available Units | Bar, mBar, hPa, kPa, MPa, PSI, kp/cm2 | ||
| Accuracy | 0.1%FS typical | ||
| Compensated Temperature Range | 0 to 50 °C | ||
| Media Temperature | -40 to +85°C | ||
| Operating Temperature | -10 to +60°C, LCD 0-50°C | ||
| Storage Temperature | -20 to +0°C | ||
| Protection | IP65 | ||
Hazardous Area Details
Intrinsically safe version LEO2-Ei in accordance with 2014/34/EU (ATEX) and IECEx
LCIE 01 ATEX 6001 X
IECEx LCIE 18.0035 X
Zone 0: Ex II 1G Ex ia IIC T5 Ga
The intrinsically safe version may only be operated using the CR2430 battery from RENATA. Part Number: LEO2-EI-BATT
Max. permitted ambient temperature range -10 to 80 °C
Scope of Delivery
We can provide the LEO2Ei-300BAR gauges with a calibration certificate. This can be done inhouse with UKAS traceable certification in 1-3 days, or at a UKAS certified calibration house in around 1 week. Available separately.
¼”NPT Swivel Adapters are available from stock and can be swapped for the ¼”BSP, if required.
