Description
Applications
- Monitoring air velocity and temperature in ducts
- Monitoring air volume based on air velocity and duct diameter
- Monitoring the proper use of air filters
(proper air velocity = proper functioning of filters)
Features
- All measurement ranges in a single device
(0…2 m/s, 0…10 m/s, 0…20 m/s) - Separate outputs for air velocity and temperature
- Available with relay output
- Easy to install on round and rectangular ducts
Specifications
| Power Supply: |
24v DC/AC ± 10% | ||
| Suitable media: | Air | ||
| Measuring Element: | PT1000 and NTC10K | ||
| Analogue Output signals: | Output Signal 1 | 0-10V (linear to ºC), L min 1kW or 4-20mA (linear to ºC), L max 400W |
|
| Output Signal 2 | 0-10V (linear to m/s), L min 1kW or 4-20mA (linear to m/s), L max 400W |
||
| Relay Output signals: | Optional relay output | Potential free SPDT 250VAC, 6A / 30VDC, 6A with adjustable switching point and hysteresis |
|
| Velocity Range: | Selectable by jumper 0-2, 0-10, or 0-20 M/S | ||
| Temperature Range: | 0 to +50°C | ||
| Materials: | ABS housing and stainless steel probe | ||
| Dimensions Housing: | 90.0 x 71.5 x 36.0mm | ||
| Dimensions Probe: | Outer diameter 10mm, length 210mm from bottom of the cover Adjustable Immersion length 50..180mm, with flange |
||
| Protection: | IP54 | ||
