VOLTAGE ATTENUATOR 100:1
The 100x attenuator divides the input voltages by a factor of 100:1 Maximum input voltage is 500vDC. Input impedance is 1MOhm. Fast mounting on all channels and has safety banana connectors on both ends and Gilded contacts...
W2-IMU
W2-IMU with configurable Gyro Rates of ±250, ±500 and ±2000°/s and Acceleration ranges of ±2, ±4, ±6, ±8 and ±16g. Unit has an internal rechargeable battery for 5 hours operation. Supplied with 3 foot micro USB cable used for charging and an ESD protective carry case...
WAF Style GFT Flow Meter
GFT Gas Flow Turbine Flow Meter with WAF Style connections. All Stainless Steel Construction with options for 4-20mA output and IS or EXD versions available...
WIRELESS-USB-SETUP
Configuration of wireless USB hub with client data logger and WiFi LAN..
WR3 Remote Mounted MID Approved Heat Meter
Minocal WR3 Remote Mounted Heat Meters with 2 x 3m PT500 temperature probe and pockets. Suitable for heating applications with a temperature range of 10 to 90°C. Units supplied with a 6 yr battery powered Heat Integrator LCD display unit...
wRemote-3004-ND
wRemote wireless remote node, with 2 analogue 0-10 or 4-20mA, 4 digital inputs, 2 digital outputs ( open collector ) Power supply 10-30vDC, operating temperature -5 to +65°C, DIN rail mounting. 1 x RS232/RS485 serial port, MODBUS protocol RTU/ASCII. 2.4GHz Zigbee radio communications, maximum range 2Km line of sight. Maximum..
WREMOTE-3106-BP
wRemote wireless remote node, with 4 analogue 0-10vDC or 4-20mA inputs and 4 digital/count inputs. Power supply internal battery. 2.4GHz ZigBee radio communications, maximum range 2KM line of sight. Housed in an IP68 enclosure. Low powered node, which will NOT relay signal from other nodes in a Mesh network...
WS400-UMB
WS400 Compact Weather Station, EU/USA version, for measuring Air Temperature, Relative Humidity, Air Pressure and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: EU/USA version has FCC ID: UF9IPS137, Lower Frequency in MHz: 24125.0, Upper Frequency in MHz: 24125.0..
WS400-UMB-UK
WS400 Compact Weather Station, UK version, for measuring Air Temperature, Relative Humidity, Air Pressure and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: UK version has FCC ID: UF9IPS149, Lower Frequency in MHz: 2435.0, Upper Frequency in MHz: 2475.0..
WS501 Weather Station
The WS501 weather station is a compact weather station for measuring Wind Speed & Direction, Air Temperature, Relative Humidity, Air Pressure and Solar Radiation. Outputs are in RS485 in the following protocols: ASCII; UMB; SDI-12; and ModBus. Available with low-power setting for remote stations with solar power and can be..
WS501-UMB
WS501 Compact Weather Station for measuring Wind Speed, Wind Direction, Air Temperature, Relative Humidity, Air Pressure and Solar Radiation. Output via RS485, in ASCII, UMB, SDI-12 and ModBus...
WS600 Weather Station
The WS600 weather station is a compact weather station for measuring Air Temperature, Relative Humidity, Air Pressure, Wind Speed & Direction and Precipitation intensity, type and quantity. Outputs are in RS485 in the following protocols: ASCII; UMB; SDI-12; and ModBus. Available with low-power setting for remote stations with solar power..
WS600-UMB
WS600 Compact Weather Station, EU/USA version, for measuring Air Temperature, Relative Humidity, Air Pressure, Wind Speed & Direction and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: EU/USA version has FCC ID: UF9IPS137, Lower Frequency in MHz: 24125.0, Upper Frequency in..
WS600-UMB-UK
WS600 Compact Weather Station, UK version, for measuring Air Temperature, Relative Humidity, Air Pressure, Wind Speed & Direction and Precipitation intensity, type and quantity. Output via RS485, in ASCII, UMB, SDI-12 and ModBus. Precipitation radar sensors: UK version has FCC ID: UF9IPS149, Lower Frequency in MHz: 2435.0, Upper Frequency in..
WTP-100
WTP-100 Wireless communications link between XR440/XR5 data logger and PC. Transmission range up to 30m indoor and 100m outdoor. Supplied with battery cable and AC power suppy for remote module with US plug...
WTP-100-EXP
WTP-100 Wireless communications link between XR440/XR5 data logger and PC. Transmission range up to 30m indoor and 100m outdoor. Supplied with battery cable and AC power suppy for remote module with UK, EU and Australian plugs...
X005-425
X005-425 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 4-20mA output. Tri-port isolation between power supply,..
X005-426
X005-426 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 20-4mA output. Tri-port isolation between power supply,..
X005-545
X005-545 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 0.5-9.5vDC output. Tri-port isolation between power supply,..
X005-546
X005-546 Galvanic Isolation Amplifier for use with Intrinsically Safe Position Sensors coded Z000. Power supply 12-30vDC. The X005 Galvanic Isolation Amplifier provides a regulated and resistively limited 5vDC power supply to the sensor and amplifies the returned ratiometric output to a factory configured 9.5-0.5vDC output. Tri-port isolation between power supply,..
X603
X603 Quarter Wave Flexi Strand Radio Modem Helical Antenna with TNC male connection. Suitable for covering local sites where aerial size is a limiting factor...
X604
X604 Half Wave Mast mounted omni-directional Dipole radio modem Antenna with TNC Male connection. 0dB Gain. Suitable for general site coverage with a 360° radiation pattern...
X605
X605 Eight Element High Gain Yagi Radio Modem Antenna. 10dB Gain. This type of antenna concentrates the signal into a 40° beam. Suitable for outstations sending readings back to an omni directional antenna at the base station or between two fixed locations...
X7301-100
CCTV Video Bridge - 1 Channel, 100mW, 1.394GHz . Range 500-1Km Line of Sight, IP67 Enclosure. External Antenna,..
