80322S3314
N322S Electronic Thermostat for Solar Water Heating Control with a SPDT Relay Output (Max 250vAC @ 16A) and a SPST Relay (Max 250vAC @ 3A2. Differential controller that compares two temperature readings. Accepts NTC Thermistor Input. Measurement Range: -50 to +120°C (-58 to 248F), Accuracy 0.6°C between -19.9 to 99.9°C,..
80322T1022
N322T Electronic Thermostat for heating and refrigeration purposes with built-in timer. Single SPDT Relay Output, Max 250vAC @ 16A. Direct Switching of compressor or electrical heater with simple ON/OFF control and a second SPST-NO Relay (Max 250vAC @ 3A) suitable for additional control or alarm. Accepts PT100 Input (NBR 13773/97..
80322T3022
N322T Electronic Thermostat for heating and refrigeration purposes with built-in timer. Single SPDT Relay Output, Max 250vAC @ 16A. Direct Switching of compressor or electrical heater with simple ON/OFF control and a second SPST-NO Relay (Max 250vAC @ 3A) suitable for additional control or alarm. Accepts NTC Thermistor Input. Measurement..
80322T4024
N322T Electronic Thermostat for heating and refrigeration purposes with built-in timer. Single SPDT Relay Output, Max 250vAC @ 16A. Direct Switching of compressor or electrical heater with simple ON/OFF control and a second SPST-NO Relay (Max 250vAC @ 3A) suitable for additional control or alarm. Accepts Thermocouple (Type J, K..
80322T4324
N322T Electronic Thermostat for heating and refrigeration purposes with built-in timer. Single SPDT Relay Output, Max 250vAC @ 16A. Direct Switching of compressor or electrical heater with simple ON/OFF control and a second SPST-NO Relay (Max 250vAC @ 3A) suitable for additional control or alarm. Accepts Thermocouple (Type J, K..
8104210000
N1040i-PR Universal Process Indicator with Pulse and single Relay Control Output, Output 1: Voltage Pulse, 5V @ 50mA Max; Output 2: SPST Relay (240vAC @ 1.5A). Sensor Input: PT100 and Thermocouples (Type J, K or T). Power Supply: 100 to 240vAC (Max 6 Watts). Operating Temperature: 0 to 50°C. IP65..
8104210014
N1040i-PR-24V Universal Process Indicator with Pulse and single Relay Control Output, Output 1: Voltage Pulse, 5V @ 50mA Max; Output 2: SPST Relay (240vAC @ 1.5A). Sensor Input: PT100 and Thermocouples (Type J, K or T). Power Supply: 12 to 24vDC (Max 6 Watts). Operating Temperature: 0 to 50°C. IP65..
8104211307
N1040i-PRRR Universal Process Indicator with Pulse and Three Relay Control Outputs, Output 1: Voltage Pulse, 5V @ 50mA Max; Output 2: SPST Relay (240vAC @ 1.5A); Output 3: SPST Relay (240vAC @ 1.5A); Output 4: SPDT Relay (240vAC @ 3A).. Sensor Input: PT100 and Thermocouples (Type J, K or T)...
8104211315
N1040i-PRRR-24V Universal Process Indicator with Pulse and Three Relay Control Outputs, Output 1: Voltage Pulse, 5V @ 50mA Max; Output 2: SPST Relay (240vAC @ 1.5A); Output 3: SPST Relay (240vAC @ 1.5A); Output 4: SPDT Relay (240vAC @ 3A).. Sensor Input: PT100 and Thermocouples (Type J, K or T)...
8104211400
N1040i-PRAR Universal Process Indicator with Pulse, Signal Retransmission and Two Relay Control Outputs, Output 1: Voltage Pulse, 5V @ 50mA Max; Output 2: SPST Relay (240vAC @ 1.5A); Output 3: 0-20mA (12,000 Levels); Output 4: SPDT Relay (240vAC @ 3A).. Sensor Input: PT100 and Thermocouples (Type J, K or T)...
8104211440
N1040i-PRAR-24V Universal Process Indicator with Pulse, Signal Retransmission and Two Relay Control Outputs, Output 1: Voltage Pulse, 5V @ 50mA Max; Output 2: SPST Relay (240vAC @ 1.5A); Output 3: 0-20mA (12,000 Levels); Output 4: SPDT Relay (240vAC @ 3A).. Sensor Input: PT100 and Thermocouples (Type J, K or T)...
8104219300
N1040T Timer/Temperature Controller with PID Function and Relay Control Outputs (1 x SPDT @ 3A and 2 x SPST @ 1.5A), Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A); Output 3: SPST Relay (240vAC @ 1.5A); Output 4: SPDT Relay (240vAC @ 3A)...
8104220300
N1040i-RA Universal Process Indicator with PID Function, Single SPDT Relay Control Output and Parameter Value Retransmission, Output 1: SPDT Relay (240vAC @ 3A); Output 2: 0-20mA (12,000 Levels); PWM Cycle (0.5 up to 100 seconds). Sensor Input: PT100 and Thermocouples (Type J, K , T, E, N, R, S, or..
8105000000
N1050-PR Temperature Controller with PID Function and Relay Control Output (1 x SPST @ 1.5A), Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A). Sensor Input: PT100 and Thermocouples (Type J, K, S or T). Power Supply: 100 to 240vAC (Max 6 Watts). Operating..
8105000040
N1050-PR-24V Temperature Controller with PID Function and Relay Control Output (1 x SPST @ 1.5A), Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A). Sensor Input: PT100 and Thermocouples (Type J, K, S or T). Power Supply: 12 to 24vDC (Max 6 Watts). Operating..
8105000200
N1050-PRAR Temperature Controller with PID Function, Two Relay Control Outputs (1 x SPST @ 1.5A, 1 x SPDT @ 3A) and Analogue Output. Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A); Output 3: 0-20mA (12,000 Levels); Output 4: SPDT Relay (240vAC @ 3A)...
8105000240
N1050-PRAR-24V Temperature Controller with PID Function, Two Relay Control Outputs (1 x SPST @ 1.5A, 1 x SPDT @ 3A) and Analogue Output. Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A); Output 3: 0-20mA (12,000 Levels); Output 4: SPDT Relay (240vAC @ 3A)...
8105002500
N1050-PRRR-RS485 Temperature Controller with PID Function, Three Relay Control Outputs (2 x SPST @ 1.5A, 1 x SPDT @ 3A) and RS485 Serial Comms, Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A); Output 3: SPST Relay (240vAC @ 1.5A); Output 4: SPDT Relay..
8105002540
N1050-PRRR-RS485-24V Temperature Controller with PID Function, Three Relay Control Outputs (2 x SPST @ 1.5A, 1 x SPDT @ 3A) and RS485 Serial Comms, Output 1: Voltage Pulse (5V @ 50mA Max); Output 2: SPST Relay (240vAC @ 1.5A); Output 3: SPST Relay (240vAC @ 1.5A); Output 4: SPDT Relay..
814-150
Magnetic holder for RayTemp38 thermometers..
820K481024
N20K48-24V Modular Controller. Mains Display shows process variable values with 11 segment alphanumeric digits. Lower Parameter Display show the Set Point Values. A Graphical Bar shows the progress of Ramps and Soaks. Various Flags for Alarm Conditions, Operations, Timers, Comms, etc. Four button keyboard on front panel. Each display has..
8300200134
N3000 Dig Digit Universal Controller suitable for PT100, Thermocouples, 4-20mA, 0-50mV and 0-5vDC inputs with Double LED display: 18mm High Red Digits for Process Variable (PV) and 13mm High Green for Setpoint Value (SV). One digital input for dry contact. Isolated 4-20mA output channel, also configurable for Digital I/O (10vDC..
8801860080
WL420 Submersible Hydrostatic Level Transmitter. Depth Range 60mH2O. 2-Wire Loop Powered 4-20mA Output with a 12-36vDC Power Supply. 80m Polyurethane (PUR) Cable with Ventilation Tube. Over-Pressure 200% FS, Burst Pressure 500% FS. Stainless Steel Sensor with 105mm Body Length and 26.5mm Diameter...
8802100200
TL400-I Non-Intrusive Laser Level Sensor. Suitable for tank level monitoring of liquids, grains or solids. Measuring Range: Up to 4m. Output Signal: 4 to 20mA, Accuracy: up to 2mm. 4-pin M12 Connector with 150mm cable. Interface: Mobile Device + SigNow Mobile App (Android and iOS). Power Supply: 8 to 33vDC...
