1733-PK-041
Replacement MetConnect Temperature and Humidity Sensor. Replacement Sensors are a direct replacement for the original supplied sensor and can be fitted into the screen and to the same M12 Connector on the MetConnect Hub Box under the mounting bracket as the existing sensor...
1771-PK-116
Anodized Aluminium Bracket with 316 grade Stainless Steel sensor mount with isolation gasket to reduce corrosion. The Bracket uses a mounting clamp suitable for attaching to a vertical pipe with a diameter of 30-58mm. When mounting the WindObserver, consider the position, orientation and alignment of the unit. Mount at the..
1957-PK-151
Maximet Marine 8-Pin M12 Connector with 2m of cable. Suitable for the GMX560 Weather Station for Power and Serial Communications...
31220011
G1/G2 (B) Deck Mount Hardware Kit..
5200-07S-BR
Set of two blocking rings for resealing pipework when flow meters are removed. Suitable for CDI-5200-07S flow meters..
6797910
19" 6U Wall-Mounted Metal Enclosure for two MX52. IP55, with window door...
812-007
M12 - U-bolt with a 90mm arc diameter. Order 4 per mounting kit...
832-015
Stainless Steel wall bracket for the 9200 series pressure manometers. Suitable for 9205, 9215, 9230 and 9275 models...
8813002001
LogBox-AA IP65 Data Logger, 2 Analogue Channels for PT100, Thermocouples (types J, K, T, E, N, R, S or B), Voltage (0 to 50mV or 0 to 10V), or Current (0 to 20mA or 4 to 20mA). with 64,000 reading memory, battery life up to 3 years. Sensor external power..
CLAN-1520-XF
cLAN Ethernet Data Logger. 2 RS232/485 Port for connecting serial devices to embedded Modbus Master for I/O Expansion, NMEA0138 or Gill Instruments WindSonics and MetPak weather stations. Event logging and Real Time Clock. Power Supply 10 to 30vDC. Dimensions: 85 x 105 x 60mm...
GS-42
GEN II radio transmitter with wired connections for up to 2 voltage/current inputs. Selectable ranges 0-100mV, 0-1vDC, 0-10vDC, 0-20mA, 4-20mA plus EU scaling configured using DARCA software. The GS-42 can also provide a 5 or 12V sensor supply. Supplied with 4 x AA Alkaline batteries and stub antenna...
GS-44
GEN II radio transmitter with wired connections for up to 4 voltage/current inputs. Selectable ranges 0-100mV, 0-1vDC, 0-10vDC, 0-20mA, 4-20mA plus EU scaling configured using DARCA software. The GS-44 can also provide a 5 or 12V sensor supply. Supplied with 4 x AA Alkaline batteries and stub antenna...
HC2A-SH
High Accuracy Standard Temperature and Relative Humidity Probe with UKAS Calibration. Temperature Range: -50 to +100°C and Humidity 0-100%. Accuracy: ±0.1°C and ±0.5%RH, adjustments at 23 °C and 10, 20, 30, 40, 50, 60, 70, 80, 90 %RH. Outputs: 0-1V. Comes with a black Polycarbonate housing and a Polyethylene (40µm)..
LEO-CASE
Soft carry case for LEO digital manometers and loggers..
LFT/IS
Intrinsically safe pick-up option. Suitable for Hazardous Installations ( Eex ia IIC T4 ) ...
MCIL5M-INLINE-MOULD
To mould inline MCIL3M 5 pin male miniature subcon connector to an existing cable This item isn't available to purchase online but is normally held in stock. You can contact us directly to check availability and pricing. info@omni.uk.com..
MIEX64122
MiniAir 64EX Mini vane anemometer. Sensing head 22mm diameter x 28mm, probe length 175mm. Air velocity range 0-20m/s with a 4-20mA output. Accuracy ±1% of full scale, ±3% of reading. Power supply 9-24vDC Sensor is supplied with 20m cable to zener barrier housing. Operating range -10 to +80°C. Plastic sensing..
MPM4730[0-10MPA]-E-R4-22-M12-C2-G
MPM4730 Programmable Pressure Transmitter with 0-100 Bar basic range. 2 Wire, 4-20mA output plus RS485 serial comms. 4 Pin M12 electrical connection with ¼" BSP process connection. Programmed pressure range available from 0-20 Bar up to 0-100 Bar...
MTN/MH008
3-Pin 62GB Mating Connector for MTN Series Sensor. Extremely robust and waterproof to IP66, bayonet fitting...
PB-6005-1M5
Standard PT100 Temperature Probe with moulded handle and connector (IP68 rated) for use with the TGP-4104 and TV-4104 data logger. The stainless steel probe is 150mm long and 5mm in diameter with a 1.5m cable. Temperature range -50 to 300°C with a 25 second response time in water...
PTM-3010
RTD (PT100, PT1000) Input Module for RTR505B(L), TR55i-PT and RTR505-PT(L) Remote Units. Compatible Sensors: PT100, PT1000 (3-wire or 4-Wire, 4th wire unused). Sensor connects using a 3 Terminal screw clamp terminal block. Measurement Range: -200 to +500°C (within the sensor heat-durability range only). Resolution: ±0.1°C. Accuracy: -40 to 10°C: ±0.5°C..
RODENDM8X1.25
Rod End Bearing to align extraneous forces through the principle axis of a load cell. M8 x 1.25 Male Right-hand Thread Construction: Hard Chromium/PTFE composite/Elgoglide sliding contact surface, with Zinc plating for corrosion resistance. Rod Eye 8mm diameter. Designation: GAR8 UK..
SC200A
SC200A Split core, self powered, AC current sensor. Current range 0-200 Amps, output 0-5vDC. Accuracy ±1% of reading from 10% to 100% of full scale. Dimensions 3.3" x 3.0" x 1.25" with a 1" square window and 8ft signal cable. Operating temperature -20 to +55°C...
Subsea Pressure Sensor
Keller series 33 subsea transmitter, ranges up to 1,360 Bar, 1/4" BSP male thread, 4-20mA Output, total error band 0.15% and RS485 Output total error band 0.1%FS. Subsea housing, external case pressure 400 Bar, with 5 pole subcon connector BH5MSS-316...
