Water detection alarm – 24vAC/DC version with buzzer and relay output.
£78.43
They are fitted as standard with LED indication of the water leak status, and sounder that can be disabled by simply removing a jumper. The WD-AMX-1 relay output can either configured to be manual or auto reset
A relay output provides an alarm signal that can be used for connection to a BMS controller or remote alarm annunciation panel such as the UI-AA1-F
Features
Specifications
| Supply: | WD-AMX-1 |
24vDC ±10% |
| Supply current: | 50mA max. | |
| Output: | SPDT relay 12A @ 230VAC | |
| Response time: | <1 sec. after exposure | |
| Sensors: | WD-CS, WD-PS, WD-RS | |
| Max. sensor cable length:Â Â Â Â | 200 metres (with leader cable) | |
| Audible alarm: | 85dB @ 2.3 kHz at 10cms. | |
| Ambient: | Temp.          Humidity       |
0 to 40°C 0 to 80% RH non-condensing |
| Dimensions: | 72 x 64 x 55mm | |
| Weight: | WD-AMX-1 |
100g |
WD-CS-2M
£29.92
WD-CS-5M
£42.45
WD-CS-10M
£68.36
WD-CS-15M
£94.21
