Specification
| Power supply | from measurement line, min. current 3.5 mA, max. voltage drop 7V |
|---|---|
| Display | LED, red, 4 x 13 mm high |
| Input | current 4-20 mA, overload-protected, input current limited to about 50 mA |
| Measurement range | -999 up to 9999 |
| Accuracy | ± 0,25% ± one digit in the entire operation range |
| Stability | typ. 50 ppm/°C |
| Storage temperature | -10°C to +70°C; -20°C to +70°C (depending on version) |
| Operating temperature | 0°C to +50°C; -20°C to +50°C (on special request) |
| Protection class | IP 40 (front side); IP 20 (case and connection clips). Optionally IP65. |
| Case | panel mounting |
| Case material | NORYL UL94 V-0 |
| Case dimensions | 72 x 36 x 77 mm |
| Panel cut-out dimensions | 67 x 32.5 mm |
| Installation depth | min. 78 mm |
