Description
Features
- Connect up to 3 RS232 Modbus inputs with a single RS485 Modbus output.
- Each serial port can be configured independently with different Baud Rates and Modbus RTU or Modbus ASCII communications.
- The SGW1 can be used as a Modbus RTU to Modbus ASCII converter.
- The SGW1 can be used as an RS232 to RS485 converter.
- Up to 32 RS485 slaves (SGW1-3100-IA2-MMP)
- No need for registers tables.
- Wide range power supply 9-30vDC.
- Easy configuration.
- Industrial pluggable terminal blocks.
- DIN Rail Mounting available.
Specifications
| Serial Protocols: | Modbus RTU/ASCII/ASCII 8 bits |
| Baud Rates: | 1200, 2400, 4800, 9600, 14400, 19200, 28800, 38400, 57600, 115200. |
| Modbus Masters: | Up to 3 ports for master devices |
| Modbus Slaves: | Up to 3 ports for slave devices |
| Power Supply: | 9 to 30vDC, 200mA max. |
| Operating Temp: | -5 to 65°C |
| Dimensions: | 114 x 100 x 22.5mm |
| Weight: | 140g |
