Description

The SER-9550 Tinytag Service Kit is a service kit for all Tinytag View2 data loggers. The kit contains all the appropriate parts required for servicing TinyView data loggers.

Instructions for servicing Tinytag View data loggers.

 Tinytag View / TinyView Loggers

For use with logger models:
TV-4020, TV-4050, TV-4076, TV-4104, TV-4204, TV-4500, TV-4501, TV-4505, TV-4506, TV-4510, TV-4704, TV-4804, TV-4810

  1. If fitted, cut off the calibration seal.
  2. Unscrew the lid and remove the foam spacers. Carefully lift out the circuit board, touching it only at the edges.
  3. Remove the old desiccant pack and the battery from its holder. Check the battery holder contacts are clean.
  4. For Tinytag View 2 data loggers (starting TV-4): Wait five minutes and then, whilst observing the correct polarity, and taking care to touch only the edges of the circuit board, insert the new battery whilst watching the unit’s display. The display should flash briefly as the battery is inserted, and then go out.
  5. Connect the data logger to the computer and check Tinytag Explorer can communicate with it.
  6. Fit the new desiccant pack and carefully replace the circuit board, ensuring the correct orientation and that no wires are trapped between the circuit board and its supports.
  7. Remove the old ’O’ ring from the box and check that the two mating surfaces and screw thread are clean before fitting the new one.
  8. Re-fit the foam spacers with their smooth sides facing up. Replace the lid, turning it until it meets the stop.
  9. Replace the connector cap lanyard if necessary.

Calibration seals, if fitted, can only be replaced by an authorised distributor.

Tinyview RH loggers that incorporate blue wires and grey ribbon cable should always be re-calibrated after the case is opened for any reason.

Please note, Omni Instruments Ltd also offers a service calibration on all Tinytag data loggers. This service includes a UKAS traceable calibration certificate, plus new batteries, seals and desiccant pack. Pricing for the service calibrations are included at the bottom of this page, as well as a calibration return form that you can return with your loggers to us.
