Description

Virtual Comm Port drivers are provided to allow a NetPort-connected device to communicate with existing software over TCP/IP (for Windows operating systems). Alternatively, 'direct socket' connection can be used.

The Development Kit (DVK) option is offered to all customers who wish to evaluate & prototype NetPort and consequently comes with a PSU* and CDROM packed with Apps Notes, User Guide & software utilities necessary to get NetPort integrated into any application in a matter of hours. We recommend all new users to evaluate using the DVK.

Specifications		Applications
10/100Mb/s AUTO SENSING RJ45 ETHERNET PORT ETHERNET ACTIVITY AND STATUS LEDS 6 PAGE WEB SERVER FOR STATIC HTML 234b/s MAXIMUM SERIAL THROUGHPUT ** MOULDED 9-WAY D-TYPE SERIAL CABLE POWER STATUS & SERIAL ACTIVITY LEDS 128bit RIJNDAEL AES ENCRYPTION (LAN03/04) SUPPLIED WITH MAINS POWER SUPPLY (DVK ONLY) POWER PASS THROUGH TO/FROM SERIAL EQUIPMENT (LAN06) POWER CONSUMPTION 240mA @ 7.5V, 75mA @ 24VDC CONFIGURABLE SECURITY OPTIONS CAN BE CUSTOMISED FOR OEM USE		FIRE AND SECURITY PANELS VENDING MACHINES EPOS (POINT OF SALE TERMINALS) REMOTE IT MANAGEMENT ACCESS CONTROL TICKETING AND FINANCIAL INSTRUMENTATION AND MEASUREMENT INDUSTRIAL CONTROL BUILDING CONTROL HANDHELD COMPUTING AUDIO VISUAL HOME AUTOMATION

Product Selection Table

	LAN01	LAN02	LAN03	LAN04	LAN06
10/100 Ethernet
230kbps serial throughput **
Simple 2 wire serial option
Handshaking serial option
9 way Plug (DTE) serial cable
9 way Socket (DCE) serial cable
7.5-24v Dc working voltage
Powered from serial equipment (DB9 pin9)
Powered from external PSU (2.5mm jack)
Power provided to serial equipment (DB9 pin 9)
Power available from spare DC socket
Telnet, Web or serial configuration options
Modem Emulation mode
TCP/IP direct socket connection
Virtual Comm Port connection
Email alerts can be sent from NetPort
DHCP client
6 page Webserver
128bit encryption on TCP/IP data
