Description
General Specifications
Memory Capacity: Over 1,000,000 measurements.
Key: Set bookmark or start and stop the recording
LED’s: Blue: Record indicator; Red: Alarm Indicator; Yellow: Battery Charging.
Power Supply: Rechargeable Lithium polymer battery rechargeable via USB connection.
| Item No. | Type & Battery | Size & Weight | Rating |
| 145WDB25 | Design Housing with 230mAh battery |
57 x 35 x 17mm approx 27g |
IP60 |
| 145WDB23 | Design housing with 900mAh battery |
57 x 35 x 25mm approx 43g |
IP60 |
| 145WDB26 |
Design Housing with
230mAh battery
|
57 x 35 x 17mm approx 36g |
IP67 |
| 145WDB22 | Design housing with 800mAh battery |
57 x 35 x 25mm
approx 62g
|
IP67 |
Technical Specifications
Measured Parameters:
| Sensor | Part Reference | Measurement Range |
| Temperature (Internal) | T9 | -20 to +65 °C |
| Temperature (External) | FT9 / FT2 Type-K FT3 |
-40 to +125 °C -200 to +1350 °C |
| Humidity with Integrated Temp |
H3 FH3 |
0 to 100 %RH, -20 to +65 °C 0 to 100 %RH, -40 to +125 °C |
| Air Pressure | P5 | 10 to 2000 mBarA, -20 to +65 °C |
| Air Pressure (External) |
FP10 FP7 |
10 to 2000 mBarA, -20 to +65 °C 0 to 14 BarA, -40 to +85 °C |
| Fluid Pressure (External) |
FP9 FP3 FP4 FP8 FP12 |
-1000 to 3000 mBar, -20 to +85 °C 0 to 3000 mBarA, -20 to +85 °C 0 to 30 BarA, -20 to +85 °C 0 to 400 BarA, -20 to +85 °C 0 to 1000 BarA, -20 to +85 °C |
| 3-Axis Acceleration | A FA |
±15 g |
| Light | L3 FL3 |
0 to 83,000 Lux |
PC Software
The integrated software in each unit includes Free Setup, Reader, Viewer and Online software (Windows XP/Vista/7/8) to record and evaluate data. All measurement parameters can be rapidly transferred to a PC via the USB connection both during the measurement operation and once the measurement task has been completed. Each unit includes an integrated clock (RTC), allowing data from as many MSR145WD units as required to be synchronised and merged into a single data record.
Android App for BLE Data Loggers
The image on the right links to the Google Play store to download the MSR DataLogger application used to enables mobile devices to connect to the BLE (Bluetooth Low Energy) MSR data loggers. The app allows for the configuration and viewing of online sensor data and can be used with multiple loggers using the wireless Bluetooth connection.
