Description

General Specifications

Memory Capacity: Over 1,000,000 measurements.
Key: Set bookmark or start and stop the recording
LED’s: Blue: Record indicator; Red: Alarm Indicator; Yellow: Battery Charging.
Power Supply: Rechargeable Lithium polymer battery rechargeable via USB connection.

Technical Specifications

Measured Parameters:

• Temperature
• Relative Humidity (includes integrated temperature)
• Pressure (e.g. altimeter, water level, barometer) (Absolute with integrated temperature)
• 3-Axis Acceleration (Static)
• Light

Working Range:
Internal Temperature: -20 to 65°C
External Temperature: -40 to +125°C
Internal Humidity (with integrated temperature): 0-100% RH, Temp (-20 to +65°C)
External Humidity (with integrated temperature): 0-100%RH, Temp (-40 to +125°C)
Internal Air Pressure (with integrated temperature): 10-2000 mBarA (Temp -20 to +65°C)
External Air Pressure (with integrated temperature): 10-2000 mBarA (Temp -40 to +85°C)
Acceleration: ±15g
Light: 0-65,000 Lux

Accuracy:
Internal Temperature:±0.2°C (-10 to +50°C)
External Temperature: ±0.2°C (-10 to +50°C), ±1°C (-40 to +125°C)
Humidity: ±1.8% RH (10-85% RH, 0 to 40°C),±4% RH (85-95% RH, 0 to 40°C)
Air Pressure: ±2mBar (750-1100mbar absolute, +25°C)
External Air Pressure (Opt P2): ±2mBar (750-1100mbar absolute, +25°C)
Acceleration: ±0.15g (25°C)
Light: Max. Sensitivity at 500 nm

WLAN (WiFi) functions

• integration either into an existing WiFi or via an access point, by means of mobile network access where required, into a separate wireless network
• WiFi range can be extended with a commercially available repeater
• data storage is guaranteed even if the transmitter fails
• alarm message if limit value is exceeded
• MSR SmartCloud: retrieve, analyse and export measured data online at any time; alarm message if limit value is exceeded
• free MSR WLAN software for graphical visualization of the measured values transmitted over WiFi (WLAN), components for LabVIEW available
