Description

The MSR Reusable Climate Data Loggers are fitted with clear status and alarm LEDs, which indicate instantly if the transport or storage conditions are within the pre-defined values. Recorded measured data of the MSR Reusable Climate Data Loggers can easily be transferred to a PC using the USB interface. When the data logger is stopped, a PDF report is automatically generated, which can be saved or printed for documentation purposes

Features

• Free MSR BudgetLine Software to configure the data logger on a PC
• Loggers have software already installed
• 6-point Calibration Certificate stored on the logger
• Fast data transfer and straight-forward data assessment on the PC
• Automatic PDF, Excel and CSV Reports of the recorded measured data
• Clear Status and alarm LEDs
• Free TLog Explorer Software for further data analysis

General Specifications

	MSR63	MSR83	MSR86	MSR64	MSR84
Memory capacity:	16,000 Values			32,000 Value (16,000 per channel)
Measuring/Storage Rate:	1 minute up to 10 days
Temperature Range:	-30 to +70°C		-100 to +150°C	-30 to +70°C
Accuracy:	±0.5°C		±0.4°C	±0.5°C
Humidity Range:	Not Applicable			0-98%RH
Accuracy:	Not Applicable			±3%RH
Battery:	Replaceable 3.0V Lithium Battery (Panasonic CR2032)
Battery Life:	Approximately 1 Year.
Interface:	USB 2.0, A-Type
Housing:	PC, ABS Food Grade, IP54, Not Encapsulated
Dimensions:	36 x 12 x 71mm	51 x 15 x 101mm	51 x 15 x 101mm	51 x 15 x 101mm	51 x 15 x 101mm
Weight:	Approx 17g	Approx 52g	Approx 56g	Approx 52g
