Description
The LL-MINI-GAUGE-050 is a 50m water level sensor with temperature measurements. The sensor incorporates a vented piezoresistive sensor to monitor depth and integral temperature sensor. This sensor does require a vent tube to the surface and does actively compensated for barometric pressure readings. This ensuring accurate readings across the full operational temperature range of -20 to +80°C. Users can select from a range of vented cables and AquaConn connectors.
The sensor housing is constructed from a carbon fibre and titanium composite. This material selection provides a high strength-to-weight ratio and enhanced corrosion resistance, critical for reliable long-term deployment in challenging environmental conditions, including saline solutions.
Features
- 0.05% FS accuracy.
- Carbon fibre and titanium body.
- 2 year warranty.
- SDI-12, RS485/MODBUS direct out communications.
- Can be connected to the AquaTel for complete remote monitoring system.
- Can be connected with the BlueLink adaptor for short-term monitoring.
- Non-vented option available
Applications
- Groundwater level monitoring, pump tests, slug tests etc.
- Stream, lake and reservoir water level measurement.
- Wetland and flood water monitoring.
- Coastal monitoring.
- Tank level measurement.
- Long term continuous monitoring in boreholes, surface water and seawater applications.
- Process applications.
- Flood warning systems.
Specifications
| GENERAL | |
|---|---|
| Temperature ranges | Operational: -20-80°C, Storage: -40-80°C, Compensated: -20-80°C |
| Diameter | 22mm |
| Length | 87mm |
| Weight | 120g |
| Materials | Titanium body, Delrin nose cone |
| Output options | Modbus/RS485, SDI-12, Aquaread proprietary |
| Battery type & life | 3.6V lithium; up to 10 years |
| External power | 6-24vDC |
| OUTPUT RATE | |
| Fastest Modbus output rate | 1 per second |
| Fastest SDI-12 output rate | 1 per second |
| SENSOR | |
| Type / Material | Piezoresistive ceramic |
| Range (Gauge) | 50.0M (328 ft) |
| Maximum pressure | Max 2x range, Burst 2.5x range |
| Accuracy (FS) | ±0.05% FS |
| Resolution | 0.002% FS or 1mm whichever is greater |
| Units of measure | Pressure: mbar (psi, kPa, bar, mbar, mmHg, inHg, cmH2O, inH2O), Level: m, ft, mm, cm and mm available in Levelink |
| TEMPERATURE SENSOR | |
| Accuracy & resolution | ±0.1°C, 0.01°C |
| Units of measure | Celsius (fahrenheit available in Levelink) |
| WARRANTY | |
| Standard | 2 years on all LeveLine-Mini versions |
| Extended | Options Available |
