Description
LevelPro liquid level sensors are used in applications ranging from measuring fuels, oils or coolants in marine vessels and off-highway machinery through to measuring the level of aggressive chemicals within manufacturing processes. Using capacitive sensing technology, LevelPro level sensors provide highly accurate and reliable contact based measurement in a wide range of liquids. LevelPro is selected where long-term reliability and lowest lifetime cost of ownership is important.
Features
- Accurate and reliable, continuous liquid level measurement, ±2% FSD @20°C
- Probe lengths available between 100mm & 2000mm
- Mounting: SAE 5-bolt, 1.125″ UNF, 1.25″ BSP or 2″ NPT thread options
- Suitable for top of tank or inverted installation
- High quality construction: 316 stainless steel construction with sealed electronics
- Durable in aggressive liquids & environments (marine grade corrosion resistance)
- Stable liquid level measurement in highly mobile vehicles
- Wide operating temperature range
- Wide tank shape and tank material compatibility with tank profiling system for irregular tank shapes
Applications
- Marine vessels including hovercraft and submarines
- Rail locomotive oil and coolant
- Off-highway machinery including high temperature & vibration environments
- Industrial and process chemicals
- Oil, fuel and coolant tanks across a range of industries
- Foaming liquids requiring accurate level measurement
