Description
The LeveLine-EWS is an Early flood Warning System that can notify you of rising water levels via SMS. The Leveline-EWS can send an SMS alarm message to up to 50 mobile phone numbers, helping give people vital time to safeguard any asset that may be at risk from flooding. You can also send the device an SMS message to get real-time water level readings.
Features
- Low cost of ownership.
- System consists of the AquaTel telemetry unit and the small LeveLine-Mini, suspended on a 10m rugged cable.
- Water level measurements are logged at regular intervals.
- Real time alerts can be sent to a number of contacts stored in the AquaTel’s phone book.
- Fully set up the device using simple SMS commands.
- Can provide the whole community with the phone number for the AquaTel, so anyone can text the device to get instant level readings.
Specifications
| SENSOR | |
|---|---|
| Type / Material | Piezoresistive ceramic |
| Range | 10.0M (32.8 ft) |
| Maximum pressure | Max 2x range, Burst 2.5x range |
| Accuracy (%FS) | ±0.05%FS |
| Resolution | 0.002%FS or 1mm whichever is greater |
| Units of measure | Pressure: mbar (psi, kPa, bar, mbar, mmHg, inHg, cmH2O, inH2O), Level: m, ft, mm, cm and mm available in Levelink |
| TEMPERATURE SENSOR | |
| Accuracy & resolution | ±0.1 °C, 0.01 °C |
| Units of measure | Celsius (Fahrenheit available in Levelink) |
| WARRANTY | |
| Standard | 2 years |
| Extended | Options Available |
