Description
Features
- Measures relative humidity and temperature, calculates the dew point
- With new HYGROMER® HT-1 sensor
- Outstanding accuracy and repeatability
- Accuracy ±0.8 %RH
- Excellent long-term stability <1 %RH / year
- Developed for very low power applications
- Digital calibration and adjustment
- Compatible with RMS data loggers and RMS software
- Conforms to FDA 21 CFR Part 11 / GAMP 5
Specifications
| Probe Type | Digital standard probe |
|---|---|
| Humidity Sensor | Hygromer HT-1 |
| Temperature Sensor | PT1000, Class B 1/3 |
| Long-term Stability | <1 %RH / year |
| Accuracy with Adjustment Profile “Standard” | ±0.8 %RH / ±0.1 K, at 10…30°C Adjustment at 23°C and 10, 35, 80 %RH |
| Reproducibility Airchip | <0.02 %RH / 0.01 K |
| Response Time t63 | <15 seconds |
| Power Consumption | 2.5…5.5vDC @ <0.5mA |
| Operating Range | -40..85°C / 0…100 %RH |
| Allowed Wind Speed | 20m/s, with filter |
| Exploitation Software | RMS-Config / RMS Server Software / RMS Cloud |
| Psychrometric Calculations | Dew or frost point |
| Software Update | Via RMS-Config / RMS Server Software / RMS Cloud |
| Digital Output Signal (Standard) | UART |
| FDA/GAMP Compatibility | FDA 21 CFR Part 11 and GAMP compatible |
| Probe Adjustment By Software | 1 Point & multipoint %RH & °C |
| Reverse Voltage Protection | Mechanically in the connector |
| Max. Cable Length | Up to 5m with passive cable. Up to 100m with active cable. |
| Probe Protection | Polycarbonate plastic cage, black |
| Filter Cartridge | Polyethylene |
| Housing | Polycarbonate |
| Dimensions | Ø15 x 108mm |
| Weight | 10 g |
| Filter Type | Polyethylene, 40μm |
