Description
Features
- Modbus protocols TCP, RTU or ASCII.
- Up to 16 simultaneous Modbus TCP connections.
- 1 HART Port.
- Modbus RS232 Port slave
- Modbus RS485 slave port optoisolated independent of the RS232.
- TCP/IP Modbus port
- Installation and configuration by Web browser.
- Software to search for Exemys devices in the network.
- DIN Rail mounting, temperature-resistant Industrial Case.
- Industrial terminal block connections.
- Wide range power supply 10 to 30 vDC.
Specifications
| Network Protocols: | Modbus TCP/IP/IP. DNS, HTTP, DHCP, ICMP, ARP. |
| Network Port: |
Ethernet 10/100 BaseT, RJ45 Connector |
| Serial Protocol: |
Modbus RTU/Modbus ASCII |
| HART Ports: | 1 |
| Serial Port: |
1 RS232, 1 RS485 optoisolated serial ports via pluggable terminal blocks |
| Supported Devices: |
Any device with HART protocol |
| Management: | HTTP Server, Password protected |
| Indicators: | Status LED, Data/Link LED |
| Power Supply: | 10 to 30vDC |
| Current Used: | 80mA @ 12vDC or 50mA @ 24vDC |
| Dimensions: | 100 x 22.5 x 112mm (H x W x D) |
| Operating Temp: | -15 to +65°C |
