Description
AirGate 4G has Wi-Fi and two Ethernet ports, which offers excellent flexibility and connectivity. The AirGate 4G fits to DIN rail and has external magnetic antennas, simplifying the installation on panels. AirGate 4G also simplifies the device access architecture, no longer requiring PLCs or SCADA systems to manage the network. The AirGate 4G Wi-Fi is designed to be used as an IoT platforms, guaranteeing secure data communication via MQTT protocol. According to the specific needs of the application, it ensures that remote access is performed securely and efficiently.
Specifications
Feature | AirGate 4G |
---|---|
Cellular Interface | 4G LTE: LTE FDD, LTE TDD 3G UMTS: DC-HSDPA, HSUPA, WCDMA 2G GSM: EDGE, GPRS 2 x SMA female antenna connector 2 x SIM (3.0 V and 1.8 V) |
Wi-Fi Interface | Standards: 802.11 b/g/n, 300 Mbps 2 x RP-SMA male antenna connector Support Wi-Fi Access Point and Client modes Security: WEP, WPA and WPA2 encryption Encryption: TKIP and CCMP |
Ethernet Interface | Standards: IEEE 802.3, IEEE 802.3u 2 x ports 10/100 Mbps, RJ45 connector 1 x WAN interface (configurable on Web GUI interface) 1.5KV magnetic isolation protection |
Serial Interface | 1 x RS232 (3 pin): TX, RX, GND 1 x RS485 (2 pin): D1, D0 Baud Rate: 300 bps to 115.200 bps 15 KV ESD protection |
Digital Input and Digital Output | 2 x Digital Inputs 2 x Digital Outputs Isolation: 3 KVDC or 2 KVrms Absolute maximum VDC: 36 VCC Absolute maximum ADC: 100 mA |
LEDs | SYS LED: Operation NET LED: Mobile network USR LED: SIM Card 1/2 3 RSSI LEDs: Strength of the cellular signal |
Software | Network protocols: DHCP, ICMP, PPPOE, HTTP, HTTPS, DNS, VRRP, NTP, MQTT, FTP, TCP, Modbus RTU master, Modbus TCP client VPN: IPSec, GRE, OpenVPN, DMVPN Policy: RIPv1/RIPv2/OSPF/BGP (optional) Firewall & Filter: Port forwarding, DMZ, anti-DoS, ACL Serial Port: TCP, UDP Management: Web Interface |
Alerts | SMS and e-mail |
Power Supply | Connector: 3-pin 3.5 mm female socket with lock Input voltage range: 9 to 48vDC |
Power Consumption | Idle: 100mA @ 12V Data Link: 400mA (peak) @ 12V |
Dimension | 106 x 106 x 40mm (excluding antenna) |
Mounting | DIN Rail Mounting |
Environmental | Operation temperature: -40 to 60°C (-40 to 140°F) Storage temperature: -40 a 85°C (-40 to 185°F) Operation humidity: 5 to 95%RH non-condensing |
Housing Metal | 300g |
Protection | IP30 |
Certification | CE, Anatel (07661-19-12560), RoHS |
