9230 Handheld Differential Pressure Meter with LCD display. Range ±30PSI (±2068mBar) Resolution 0.01PSI (1mBar). Accuracy ±0.3%FS. IP65 ABS case with integrated rubber seal. Dimensions: 32 x 71 x 141mm, weight 220g. Supplied complete with 3 x 1.5V AAA batteries, operation manual and two 500mm long x 4mm ID connection hoses

£110.00

Need help finding the right product?

Description

Features9230 Pressure Connection

  • 11 different pressure measurement units, including mBar, Bar, PSI, kPa
  • Small barbed stainless steel connectors suitable for 4mm ID tubing
  • Record function for Max, Min and Average measurements
  • Over pressure protection to twice meters range
  • Automatic power off function.
  • Replaceable AAA batteries
  • Units supplied with batteries, user guide and 500m x 4mm tubing.
  • Protective silicone boot with foot stand and magnetic mounting available
  • 12 month manufacturer guarantee

Applications

  • Flue draught measurement
  • Gas pressure in heating appliances
  • Air conditioning ducts
  • Monitoring of filters differential pressure
  • Velocity measurement with a pitot tube

The 9230 manometer covers a differential pressure range of ±30 PSI (±2068 mBar) with a resolution of 0.01 PSI (1 mBar) and ±0.3%FS accuracy. The manometer features over pressure protection to 4 PSI. The meter is easy to use and ideal for measuring non-corrosive gauge or differential air pressure in a wide variety of different industries.

Each pressure meter features a custom, LCD display with P1, P2, diff, hold, open circuit, low battery indication and a user selectable backlight. The unit incorporates an auto-power off facility that automatically turns the instrument off after approximately ten minutes, maximising battery life.

Specifications

Displayed Units: Range Resolution
PSI ±30 0.01
mBar ±2068 1
Bar ±2.068 0.001
KPa ±206.8 0.1
inHg ±61.08 0.01
mmHg ±1551 1
ozin² ±480.0 0.1
inH2O ±830 1
ftH2O ±69.20 0.01
cmH2O ±2109 1
Kgcm² ±2.109 0.001
Accuracy: ±0.3%FS @ 25°C
Repeatibility: ±0.2% (Max. 0.5% FS)
Battery: 3 x 1.5V AAA Batteries
Battery Life: 100 Hours
Display: Custom LCD
Dimensions: 32 x 71 x 141mm
Weight: 220g

Each unit is housed in a durable, ABS case that has an integrated rubber seal to ensure complete water tightness and help reduce the possibility of damage in harsh environments. Supplied complete with a battery, operation manual and two 500mm long connection hoses. A protective silicone boot with foot stand and magnetic mounting and a stainless steel wall bracket are available on request.
