N322 Electronic Thermostat for Cooling/Heating Control with Single SPDT Relay Output, Max 250vAC @ 16A. Direct Switching of compressor or electrical heater with simple ON/OFF control and a second SPST-NO Relay (Max 250vAC @ 3A) suitable for additional control or alarm. Accepts Thermocouple (Type J, K or T) Input. Measurement Range: Type J, 0 to +600°C; Type K, -50 to 999°C; Type T, -50 to +400°C. Accuracy 0.2%FS, ±2°C @ 25°C. Power Supply: 100-240vAC @ 5 Watts. Dimensions: 75 x 33 x 75mm. Panel cut-out: 70 x 29mm. Operation Temperature: 0 to 40°C. Polycarbonate Housing: IP42 | Front: IP65. Certifications: CE, UKCA, UL.
£48.51
The N322 Electronic Thermostats are designed for cooling and heating control using a SPDT Relay (Max 250vAC @ 16A) to activate or deactivate a compressor or electronic heater with simple ON/OFF control and a second SPST-NO Relay (Max 250vAC @ 3A) suitable for control or alarm. The N322 accepts Thermocouple (Type J, K or T) Input. Measurement Range: Type J, 0 to +600°C; Type K, -50 to 999°C; Type T, -50 to +400°C.
| Sensor | Thermocouple | ||
| Type | J | K | T |
| Measurement Range | 0 to 600°C | -50 to +999°C | -50 to +400°C |
| Accuracy | 0.2 % F.S. ± 2 °C @ 25 °C | ||
