N321 Electronic Thermostat for General Cooling/Heating Control with Single SPDT Relay Output, Max 250vAC @ 16A. Direct Switching of compressor or electrical heater, with programmable delay on power up. Accepts Thermocouple (Type J, K or T) Input. Measurement Range: Type J, 0 to +600°C; Type K, -50 to 999°C; Type T, -50 to +400°C. Accuracy 0.2%FS, ±2°C @ 25°C. Power Supply: 100-240vAC @ 5 Watts. Dimensions: 75 x 33 x 75mm. Panel cut-out: 70 x 29mm. Operation Temperature: 0 to 40°C. Polycarbonate Housing: IP42 | Front: IP65. Certifications: CE, UKCA, UL.
£40.31
The N321 Electronic Thermostats include a single control relays and are designed to measure, indicate and control temperature in many different systems by controlling a single relay that allows a compressor, or electronic heater, to bring the temperature back within the set point temperature limits (SP1, setpoint 1) set on the display. The N321 accepts Thermocouple (Type J, K or T) Input. Measurement Range: Type J, 0 to +600°C; Type K, -50 to 999°C; Type T, -50 to +400°C.
Users can program the control action according to the application, direct action (refrigeration) or reverse action (heating). A single SPDT Relay (Max 250 @ 16A) allows for power a connected compressor, or electric heater, with ON/OFF control.
| Sensor | Thermocouple | ||
| Type | J | K | T |
| Measurement Range | 0 to 600°C | -50 to +999°C | -50 to +400°C |
| Accuracy | 0.2 % F.S. ± 2 °C @ 25 °C | ||
