GMX200 Weather Station

Description

The GMX200 (Part Number 1957-0200-60-000) combines wind speed and direction sensing with integrated compass, and inclinometer. This comprehensive wind sensor package compensates for orientation, and tilt, making it ideal for fixed installation, or matching orientation to nearby wind instruments.

Wind

  • Relative Wind Speed & Direction. Relative to the North Marker
  • Average Wind Speed & Direction. Short and Long Term Averages
  • Corrected Wind. Corrected to Magnetic North
  • Gust Speed & Direction (WMO)

Inclinometer/Compass

  • Compass Reading (0-359° Magnetic North)
  • X -Tilt. +ve East, -ve West
  • Y -Tilt. +ve North, -ve South
  • Z Orientation, +1 Normal Upright, -1 Inverted Position
  • X & Y Can Provide 2 Decimal Points for Easy Installation.

Additional Parameters

  • Twilight. (Civil, Nautical and Astronomical)
  • Time of Sunrise, Solar Noon, Sunset (Location Required)
  • Position of the Sun
  • Supply Voltage
  • System Status
  • System Time and Date
  • Custom User Information (up to 16 character)

Parameter Specifications

Parameter Range Resolution Accuracy Units of Measure
Wind Speed 0-60m/s 0.01m/s 0.3m/s (0-10m/s)
3% (10-40m/s)
5% (40/60m/s)		 m/s, Km/h, mph,
kts, ft/min
Wind Direction 0-360° 1° ±3° (0.5-40m/s)
±5° (40-60m/s)		 Degrees
Compass 0-360° 1° ±3° Degrees

GMX200 Specifications

Output Rate: 1Hz, 1 reading per minute, 1 Reading per hour, or Polled Mode
Digital Comms: RS232, RS485, RS422, SDI-12, NMEA, Modbus, ASCII
Power Supply: 5-30vDC
Consumption: 22mA
IP Rating: IP66
Operational Temperature Range: -35 to +70°C
CE Marking: Yes
Dimensions: 169.5 x 142 x 142mm
Weight: 0.5Kg
Origin: UK
Warranty: 24 Months

The GMX200 helps ensure safe lifting operations on construction sites by providing accurate wind data that accounts for crane jib movement. Its built-in compass corrects wind readings for both magnetic north and the instrument’s orientation, minimizing the risk of loads being displaced by strong gusts.
