MINI64342
MiniAir 64 Micro Steel vane anemometer with external electronic housing. Air velocity range 0-20m/s with a 2-wire 4-20mA output. Accuracy ±1% of full scale, ±3% of reading. Power supply 9-24vDC. Sensor is supplied with 5m cable for connection to the external electronics box and 2m flying lead. Operating range -10..
MINI64442
MiniAir 64 Micro high temperature Steel vane anemometer with external electronic housing. Air velocity range 0-20m/s with a 2-wire 4-20mA output. Accuracy ±1% of full scale, ±2% of reading. Power supply 9-24vDC. Sensor is supplied with 2.4m cable for connection to the external electronics box and 2m flying lead. Operating..
PCCET
Extended Cable for PyroCouple Sensor with 4 wire, T Type ThermoCouple and 4-20mA output (option 2), price per m. Max 30m total cable length. Only available when ordered with a sensor...
TR8208
Mains charger for the Tracer LiFePO4 Battery Packs with Neutrix connector. Input: 100-240V ~ 50/60Hz, 3.0A Max. Output: 29.2V 5A. Supplied with UK, Euro, US or Asian power adapters (Please highlight at time of order). Charge Times: 20Ah @ 5-7Hrs...
TT-PO521-250
Stainless Steel 316 thermowell with 1/2 inch BSPT male thread suitable for temperature probes up to 6mm in diameter. Overall length 250mm with an immersion length of 211mm and external diameter of 9.45mm (internal diameter 6.25mm). Suitable for use in systems up to 16 Bar with a max flow rate..
BATT-12V-14AH-LP
Tracer Lithium Polymer (LiPo) rechargeable battery pack, 12V @ 14Ah. Operating temperature -10 to +60°C. Run time: 3Hrs @ 50W. Recharge time: 10-16 Hrs with 1.65A charger. Life: 300+ cycles. Dimensions: 115 x 161 x 56mm, weight 950g. Battery Pack comes supplied with a Neoprene carry case, 12V cigar socket..
PCCEJK
Extended Cable for PyroCouple Sensor with 4 wire, J or K Type ThermoCouple and 4-20mA output (option 3 or 4), price per m. Max 30m total cable length. Only available when ordered with a sensor...
MiniAir6 Steel Anemometers with Separate Electronic Housing
These MiniAir 6's are vane anemometer with a separate electronics housing for measuring the flow velocities of corrosive, high temperatures gases up to a maximum temperature of 140°C. The MiniAir 6 will provide a linear 0-2V output for flow ranges of 0-20 or 0-40m/s. Units with Stainless Steel turbines are..
MiniAir6 Vane Anemometers with Separate Electronic Housing
These MiniAir 6's are vane anemometer with a separate electronics housing for measuring the flow velocities of gases with a linear voltage output. The separate electronics housing allows the standard Plastic, Aluminium snaphead to be used for air flow measurements up to 140°C. The electronics can be used to a..
MiniAir60 High Temperature Steel Anemometers with Separate Electronic Housing
These MiniAir 60's are Steel vane anemometer for high temperature air and gas flows with a separate electronics housing with a linear frequency output. The separate electronics housing allows the Steel anemometer to be used for air flow measurements up to 250°C. The MiniAir 60 provides a 0-4vDC/TTL output relative..
MiniAir60 Steel Anemometers with Separate Electronic Housing
These MiniAir 60's are vane anemometer with a separate electronics housing for measuring the flow velocities of corrosive, high temperatures gases up to a maximum temperature of 140°C. The MiniAir 60 will provide a linear 0-4vDC/TTL output for flow ranges of 0-20 or 0-40m/s. Units with Stainless Steel turbines are..
MiniAir64 High Temperature Steel Anemometers with Separate Electronic Housing
These MiniAir 64's are Steel vane anemometer for high temperature air and gas flows with a separate electronics housing with a linear current output. The separate electronics housing allows the Steel anemometer to be used for air flow measurements up to 250°C. The MiniAir 64 provides a 4-20mA output relative..
BATT-12V-22AH-LP
Tracer Lithium Polymer (LiPo) rechargeable battery pack, 12V @ 22Ah. Operating temperature -10 to +60°C. Run time: 4Hrs 20 mins @ 50W. Recharge time: 14-20 Hrs with 1.65A charger. Life: 300+ cycles. Dimensions: 115 x 161 x 56mm, weight 1.25Kg. Battery Pack comes supplied with a Neoprene carry case, 12V..
MiniAir64 Steel Anemometers with Separate Electronic Housing
These MiniAir 64's are vane anemometer with a separate electronics housing for measuring the flow velocities of corrosive, high temperatures gases up to a maximum temperature of 140°C. The MiniAir 64 will provide a linear 4-20mA output for flow ranges of 0-20 or 0-40m/s. Units with Stainless Steel turbines are..
PCCEHT
Extended Cable for High Temperature Cooled PyroCouple Sensor (option HT), price per m. Max 30m total cable length. Only available when ordered with a sensor...
MiniAir64 Vane Anemometers with Separate Electronic Housing
These MiniAir 64's are vane anemometer with a separate electronics housing for measuring the flow velocities of gases with a linear current output. The separate electronics housing allows the standard Plastic, Aluminium snaphead to be used for air flow measurements up to 140°C. The electronics can be used to a..
MINIJU222
MiniAir20 Mini vane anemometer. Air velocity range 0.4-20m/s with accuracy ±1% of full scale, ±3% of reading. Sensing head 22mm diameter x 28mm, probe length 175mm. Sensor is supplied with 1.8m cable and connector for interfacing with MiniAir Junior display. Plastic sensing head with Aluminium blade turbine suitable for non-aggressive..
MINIJU224
MiniAir20 Mini vane anemometer. Air velocity range 0.5-40m/s with accuracy ±1% of full scale, ±3% of reading. Sensing head 22mm diameter x 28mm, probe length 175mm. Sensor is supplied with 1.8m cable and connector for interfacing with MiniAir Junior display. Plastic sensing head with Aluminium blade turbine suitable for non-aggressive..
MINIJU232
MiniAir20 Macro vane anemometer. Air velocity range 0.3-20m/s with accuracy ±1% of full scale, ±3% of reading. Sensing head 85mm diameter x 80mm, probe length 225mm. Sensor is supplied with 1.8m cable and connector for interfacing with MiniAir Junior display. Plastic sensing head with Aluminium blade turbine suitable for non-aggressive..
MINIJU234
MiniAir20 Macro vane anemometer. Air velocity range 0.4-40m/s with accuracy ±1% of full scale, ±3% of reading. Sensing head 85mm diameter x 80mm, probe length 225mm. Sensor is supplied with 1.8m cable and connector for interfacing with MiniAir Junior display. Plastic sensing head with Aluminium blade turbine suitable for non-aggressive..
MINIWATER6MINIHIRE
MiniWater6 probe range 0-5 M/Sec water velocity with SQ2010 logger, and telescopic probe. Complete with software and carry case. Hire charge per week..
Minol Compact Heat Meter
Minocal Compact MID Approved kWh Heat Meters with 1.5m PT500 temperature probe and Tee ball valve. Suitable for heating or cooling applications with a temperature range of 15 to 150 C (meter max 90 C). Units are fitted with an integrated, or detached, LCD multifunction display with a pulse or..
MPM4730[0-100MPA]-E-R4-22-M12-C2-G
MPM4730 Programmable Pressure Transmitter with 0-1,000 Bar basic range. 2 Wire, 4-20mA output plus RS485 serial comms. 4 Pin M12 electrical connection with ¼" BSP process connection. Programmed pressure range available from 0-200 Bar up to 0-1,000 Bar...
31220011
G1/G2 (B) Deck Mount Hardware Kit..
